ABB SDCS-CON-1 Control Panel

Product Description

Key Specs

• System Compatibility: Exclusive to ABB ACS800 series inverters (all frame sizes R1-R11); connects to the inverter’s control board (e.g., SDCS-CON-11) via a dedicated 15-pin D-sub connector (cable included, length 1.5m); compatible with inverter firmware v3.0+.
• Display & Operation:
  • Display: 4-line backlit LCD (20 characters/line), high contrast (adjustable 3 levels) — visible in low-light (e.g., inverter cabinets) or bright industrial environments.
  • Operation Interface: 8 tactile function keys (labeled: Start, Stop, Forward, Reverse, Reset, Enter, Escape, Menu) + a navigation dial (for parameter scrolling/value adjustment); keys with tactile feedback for reliable operation with gloves.
• Core I/O for Local Control:
  • 2 digital inputs (DI): For external remote start/stop (24V DC sinking, 18-30V DC).
  • 1 analog input (AI): For external speed reference (4-20mA DC, 12-bit resolution).
  • 1 digital output (DO): For status indication (24V DC, 0.5A, e.g., "inverter running").
• Mechanical & Environmental:
  • Dimensions (W×H×D): 180mm×100mm×50mm (panel-mounted); weight ~350g.
  • Protection Degree: IP54 (dust-proof, water-splash resistant) — suitable for on-site mounting outside inverter cabinets.
  • Operating Conditions: -10°C~+60°C, 5%-95% RH (non-condensing); vibration resistance: 10-500Hz (0.5g acceleration).
• Mounting: Panel-mounted (cutout size: 152mm×76mm) with included gasket for IP54 sealing; optional handheld adapter (accessory) for temporary on-site debugging.

Core Functions

1. Local Inverter Control:
   • Executes basic inverter operations: Start/stop, forward/reverse rotation, and speed adjustment (via navigation dial or external AI reference). Supports "Local/Remote" mode switching — enables seamless handover between panel control and PLC/SCADA control.
   • Locks critical functions (e.g., parameter modification) via a 4-digit password to prevent unauthorized operation (e.g., accidental speed changes in production).
2. Real-Time Status Monitoring:
   • Displays key inverter and motor parameters simultaneously (4 parameters at once, configurable):
     • Inverter: Output frequency, DC bus voltage, input current, fault code.
     • Motor: Running speed, torque, winding temperature (if motor PTC is connected).
   • Visualizes operating states via LCD icons (e.g., "Forward" arrow, "Fault" warning triangle) and backlight color change (green = normal, red = fault).
3. Parameter Management:
   • Accesses 1000+ inverter parameters (e.g., acceleration/deceleration time, motor rated current) via categorized menus (e.g., "Motor Setup", "Control Logic"); search parameters by number or keyword (e.g., "torque limit") to reduce navigation time.
   • Saves/loads up to 5 parameter sets to internal memory (non-volatile) — enables quick commissioning of multiple identical ACS800 inverters (e.g., 10 conveyors in a mine).
4. Fault Diagnostics & Troubleshooting:
   • Logs the last 20 fault events (with timestamp, fault type, and trigger values: e.g., "Overcurrent at 50Hz, 120A"); displays fault descriptions (not just codes) for quick identification (e.g., "OC1: Output Overcurrent").
   • Provides built-in diagnostic tools: Measures AI/DI signal levels (e.g., checks if 4-20mA speed reference is valid) and verifies communication with the inverter control board — reduces reliance on external test equipment.

Core Advantages

1. Enhanced Usability vs. Basic Panels: 4-line LCD and navigation dial simplify monitoring of multiple parameters (vs. 2-line basic panels), while tactile keys ensure reliable operation with industrial gloves (critical for mining/metallurgy).
2. IP54 Durability: Water-splash and dust resistance allow mounting outside inverter cabinets (e.g., on machine frames) — eliminates the need to open cabinets for daily operation, reducing maintenance time.
3. Integrated Local I/O: Built-in DI/AI/DO for external signals (e.g., remote start, speed reference) eliminates the need for additional I/O modules, saving panel space and wiring costs.
4. Seamless ACS800 Integration: Optimized for ACS800 inverters — no protocol conversion needed; parameter menus are tailored to inverter functions (e.g., "Regenerative Braking" settings), avoiding generic HMI compatibility issues.

Applications

1. Mining Inverter Control:
   • Mounted on ACS800 inverters driving mine conveyor motors — operators use the panel to start/stop conveyors, adjust speed via the navigation dial, and monitor load current (to prevent overloading). IP54 protection withstands dust and occasional water splashes in mine shafts.
2. Metallurgical Rolling Mills:
   • Used with ACS800 inverters controlling roll motors — technicians access "Torque Control" parameters via the panel to fine-tune roll pressure; fault logs help diagnose issues like "overcurrent during steel strip feeding" for quick troubleshooting.
3. Power Plant Auxiliary Drives:
   • Installed on ACS800 inverters for boiler feedwater pumps — displays DC bus voltage and motor temperature in real time; password protection locks "Speed Reference" parameters to prevent unauthorized changes that could disrupt boiler water supply.
4. Water Treatment Pumps:
   • Connected to ACS800 pump inverters — the panel’s AI input accepts a 4-20mA signal from a tank level sensor (local speed reference), while the DO outputs a "pump running" signal to a local indicator. Operators use the menu to configure "Dry-Run Protection" parameters.

Precautions

1. Compatibility Check:
   • Confirm the ACS800 inverter’s firmware version is v3.0+ — older firmware (v2.x) does not support the panel’s 4-line LCD or parameter keyword search. Ensure the inverter’s control board is SDCS-CON-11 or newer (older boards lack the 15-pin D-sub connector).
2. Mounting & Sealing:
   • For panel-mounted installation, ensure the cutout size is exactly 152mm×76mm — oversized cutouts compromise IP54 sealing; use the included gasket and tighten mounting screws to 1.0-1.2N·m (over-tightening damages the panel housing).
   • When using the handheld adapter, avoid pulling the 1.5m cable forcefully — the D-sub connector is not designed for frequent mating (max 500 cycles); use handheld mode only for temporary debugging.
3. Environmental Limits:
   • Do not expose to high-pressure water jets (IP54 is splash-resistant, not waterproof); clean the panel surface with a damp cloth (no corrosive cleaners like acetone) to avoid LCD or key damage.
   • Operate within -10°C~+60°C — below -10°C, the LCD backlight may dim temporarily; above 60°C, key responsiveness degrades.
4. Parameter Safety:
   • After commissioning, set a 4-digit password to lock "Critical Parameters" (e.g., motor rated current, overcurrent limit) — prevent accidental modification that could lead to inverter or motor damage.
   • Back up parameter sets to the panel’s internal memory before firmware updates — updates may reset parameters to default values.
5. Wiring for Local I/O:
   • For the panel’s DI/AI/DO, use 0.5-1.0mm² copper cables; torque terminal screws to 0.5-0.8N·m. Separate analog wiring (AI) from digital wiring (DI/DO) by ≥5cm to reduce noise interference.
   • Ensure the 24V DC power for DI/AI is isolated from the inverter’s auxiliary power — shared power supplies cause ground loops and incorrect signal reading
