ABB SD812V1 3BSC610045R2 Power Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB SD812V1 is an industrial-grade power module designed to provide stable DC auxiliary power to control boards, drive boards, and I/O modules. It features overload, short-circuit, and overvoltage protection to ensure stable operation of internal control modules, I/O modules, and drive units. Suitable for industrial automation equipment, drive systems, and control cabinet power management.

Technical Specifications (Typical)

• Model: SD812V1 3BSC610045R2

• Type: Power Module

• Function: Provides auxiliary power to control boards, drive boards, and I/O modules

• Input Voltage: 24 V DC

• Output Voltage: 24 V DC

• Output Power: Max. 120 W

• Maximum Output Current: 5 A

• Power Consumption: ≤ 25 W

• Interface: Modular slot interface

• Operating Temperature: –25℃ to +70℃

• Storage Temperature: –40℃ to +85℃

• Relative Humidity: 5% to 95%, non-condensing

• Protection Degree: IP20

• Mounting: DIN rail or slot installation

• Dimensions: approx. 160 × 120 × 50 mm

• Weight: approx. 0.7 kg

Advantages & Key Features

1. Stable power supply: Provides reliable DC power for stable operation of control and drive systems.

2. Comprehensive protection: Overload, short-circuit, and overvoltage protection ensures system safety.

3. Modular design: Easy installation, replacement, and system expansion.

4. Industrial-grade reliability: Resistant to high temperature, humidity, and EMI.

5. Compact design: Saves control cabinet space and facilitates system integration.

6. Spare part availability: Suitable for replacement in legacy or discontinued systems.

Application Areas

• Internal power management in automation control systems

• Auxiliary power for ABB control boards, drive boards, and I/O modules

• Automation equipment in power, oil, gas, chemical, and metallurgical industries

• Control cabinets for industrial robots, machine tools, and production line equipment

• System maintenance and spare part replacement for legacy systems

Precautions

1. Ensure module compatibility with the control system or drive board before installation.

2. Install or remove the module only with power off.

3. Avoid high temperature, high humidity, or strong EMI environments.

4. Periodically check terminal and slot connections to ensure proper electrical contact.

5. Backup control parameters and configuration data before system upgrades or maintenance.

6. For discontinued or legacy systems, confirm stock and alternative solutions in advance.
