- ABB SC520 3BSE003816 Submodule Carrier

  1. Product Overview

  The ABB SC520 3BSE003816 is an industrial-grade submodule carrier designed for ABB automation systems (e.g., AC 800M DCS). It serves as a mechanical and electrical platform to mount, power, and enable communication between compatible I/O submodules (e.g., digital/analog input/output modules), ensuring seamless integration into centralized control systems for harsh industrial environments.

  2. Technical Specifications

  2.1 Carrier Performance
  - Submodule Slots: 2 independent slots (supports ABB standard I/O submodules, e.g., DSDI 110A, DSDO 115A)
  - Communication Interface: Integrates with AC 800M system bus (high-speed data transfer; up to 100 Mbps)
  - Power Distribution: Supplies 24 V DC ±15% to mounted submodules (max 5 A total output for 2 slots)
  2.2 Electrical & Isolation
  - Supply Voltage: 24 V DC ±15% (powered via system backplane or external redundant supply)
  - Power Consumption: Typical 2 W (carrier alone); Maximum 7 W (with 2 fully loaded submodules)
  - Isolation: 2 kV AC between system bus and submodule slots; 500 V AC between adjacent submodule slots
  2.3 Mechanical & Environmental
  - Dimensions: 140×75×30 mm (Length×Width×Height); fits standard DIN rail cabinets
  - Mounting: DIN rail (compliant with EN 50022 standard); compatible with ABB system racks
  - Operating Temperature: -25°C ~ +70°C (adapts to extreme industrial conditions)
  - EMC Compliance: EN 61000-6-2 (industrial immunity); EN 61000-6-4 (industrial emissions)
  3. Application Fields
  - Process Control: Chemical/petrochemical plants (carries analog input submodules for pressure/temperature sensors, paired with digital output submodules for valve control)
  - Power Generation: Thermal/hydro power plants (mounts submodules for turbine vibration monitoring and generator control signals)
  - Manufacturing: Automotive assembly lines (integrates submodules for conveyor sensor inputs and robotic actuator outputs)
  - Water Treatment: Wastewater plants (carries submodules for level switch inputs and pump control outputs)
  4. Installation & Maintenance

  4.1 Installation
  - Mount on EN 50022 DIN rail or ABB system rack; reserve 30 mm clearance on both sides for heat dissipation
  - Align submodules with carrier slots and push until locked (ensure proper connector engagement); power off system before submodule insertion/removal
  - Connect carrier to system bus via dedicated port (follow ABB wiring diagram for polarity)
  4.2 Maintenance
  - Check status LEDs monthly (green = normal operation; red = bus fault/submodule error)
  - Inspect submodule locks quarterly (ensure no loosening due to vibration); clean carrier surface with dry soft brush
  - Replace carrier if bus communication fails after submodule replacement and wiring check (indicates internal bus interface damage)
