ABB SAFT177SAC Analog Input Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB SAFT177SAC Analog Input Module is an industrial-grade analog input module for ABB drive systems and automation control platforms. It converts external sensor analog signals (such as voltage, current, temperature, or pressure) into digital signals for real-time monitoring and control by the control unit or higher-level systems.
The SAFT177SAC module is widely used in motor drives, automated production lines, and industrial process control systems, ensuring accurate and stable data acquisition.

2. Main Technical Specifications (Typical)

• Model: SAFT177SAC

• Product Type: Analog Input Module

• Number of Channels: 8–16 channels (depending on model)

• Input Signal Type:

  • Voltage: 0–10 V

  • Current: 4–20 mA

  • Thermocouple / RTD (select models)

• Resolution: 16-bit ADC

• Sampling Rate: Typically 1 kHz per channel

• Accuracy: ±0.5% FS (full scale)

• Isolation: Input signals isolated from module control circuitry

• Communication Interface: Compatible with ABB control units, internal bus communication

• Operating Voltage: DC 24V (supplied by control unit)

• Mounting: Plug-in or cabinet modular installation

• Operating Environment: -25 ℃ to +60 ℃

• System Compatibility: ABB drive systems, BCU series, and industrial automation platforms

3. Key Advantages and Features

1. High-Precision Signal Acquisition

   • Supports multiple industrial sensor inputs

   • 16-bit high-resolution ADC improves control accuracy

2. Fast Response and Real-Time Acquisition

   • High sampling rate for fast industrial control

   • Real-time data transmission to the control unit

3. Safety Isolation Design

   • Inputs isolated from control unit

   • Improves system safety and reduces interference

4. Modular Design

   • Plug-in installation for easy replacement and maintenance

   • Minimizes downtime

5. Strong System Compatibility

   • Fully compatible with ABB drive and control systems

   • Can be integrated with PLC/DCS systems

4. Typical Applications

• ABB inverters and drive systems analog signal acquisition

• Monitoring motor temperature, current, pressure, etc.

• Automated production lines and assembly equipment

• Metallurgy, mining, power, and chemical industry equipment

• Industrial process control and data acquisition systems

• Fans, pumps, compressors, and conveyor control

5. Installation and Maintenance Notes

1. Verify Sensor Type and Range

   • Ensure input signal type and range match the module

2. Power-Off Before Installation

   • Disconnect system power before installing or removing the module

3. ESD Protection

   • Use anti-static precautions during handling

4. Proper Wiring

   • Secure input signal wiring

   • Avoid interference from high-voltage lines

5. Environmental Conditions

   • Avoid high temperature, humidity, and corrosive environments

   • Ensure proper ventilation in the control cabinet

6. Periodic Inspection

   • Check signal wiring and acquisition accuracy

   • Ensure analog input module functions correctly
