ABB SAFT168PAC Pulse Amplifier Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB SAFT168PAC is an industrial-grade pulse amplifier board used in drive or control systems. It amplifies low-level control signals into high-level pulse signals to drive power switches, relays, or actuators. This module features high-speed response and is suitable for automation production lines, servo systems, and control board signal amplification in industrial equipment.

Technical Specifications (Typical)

• Model: SAFT168PAC

• Type: Pulse Amplifier Board

• Input Signal: TTL / logic-level signal

• Output Signal: High-level pulse signal for driving power loads

• Response Time: < 1 µs (typical)

• Supply Voltage: 24 V DC

• Power Consumption: ≤ 10 W

• Interface: Modular slot interface

• Operating Temperature: –25℃ to +70℃

• Storage Temperature: –40℃ to +85℃

• Relative Humidity: 5% to 95%, non-condensing

• Protection Degree: IP20

• Mounting: DIN rail or slot installation

• Dimensions: approx. 160 × 160 × 120 mm

• Weight: approx. 0.35 kg

Advantages & Key Features

1. High-speed response: Microsecond-level pulse amplification ensures precise control.

2. Stable signal: Provides reliable high-level pulse output for power driving.

3. Modular design: Easy to install, replace, and maintain.

4. Industrial-grade reliability: Suitable for harsh environments and long-term operation.

5. Compact size: Saves space in control cabinets and integrates easily into existing systems.

6. Spare part availability: Suitable for replacement in legacy or discontinued systems.

Application Areas

• Pulse signal amplification in automation control systems

• Servo drives, variable frequency drives, and motor control systems

• Industrial robots, machine tools, and automated production lines

• Control systems in power, oil, gas, and chemical industries

• System maintenance and spare part replacement for legacy systems

Precautions

1. Ensure module compatibility with the control system or drive board before installation.

2. Install or remove the module only with power off.

3. Avoid installation in high temperature, high humidity, strong vibration, or strong EMI environments.

4. Periodically check slot and terminal connections for proper contact.

5. Backup control parameters and configuration data before system upgrades.

6. For discontinued or legacy systems, confirm stock and alternative solutions in advance.
