1. Product Overview

ABB SAFT 1000F660 Drive Transformer is a dedicated transformer for ABB drive systems, designed to provide voltage transformation, electrical isolation, and system protection for inverters, rectifiers, and other power electronic equipment.
Optimized for the operating characteristics of ABB drives, this transformer effectively mitigates harmonics, voltage fluctuations, and electromagnetic interference, enhancing the safety, stability, and efficiency of the entire drive system. It is suitable for medium- to high-power industrial applications.

2. Main Technical Specifications (Typical)

• Model: SAFT 1000F660

• Product Name: Drive Transformer

• Rated Power: Approx. 1000 kVA (subject to system configuration)

• Rated Input Voltage:

  • Medium or low voltage industrial power supply (depending on design)

• Rated Output Voltage:

  • Customized voltage levels matched to ABB drive and rectifier systems

• Rated Frequency: 50 / 60 Hz

• Phase: Three-phase

• Insulation Class: Industrial-grade insulation for continuous operation

• Cooling Method:

  • Natural air cooling or forced air cooling (depending on configuration)

• Connection Type:

  • Commonly Δ / Y or Y / Y, customized per application

• Installation Method:

  • Floor-mounted or cabinet-integrated installation

• Design Features:

  • Excellent electrical isolation

  • High short-term overload capability

• Operating Environment:

  • Industrial-grade environment

  • Suitable for continuous operation

3. Key Advantages and Features

1. Optimized for ABB Drive Systems

   • High compatibility with ABB inverters and rectifiers

   • Improves overall system stability

2. Excellent Electrical Isolation and Safety

   • Effectively isolates the power grid from drive equipment

   • Reduces the impact of electrical faults

3. Strong Harmonic Withstand Capability

   • Designed for inverter operating conditions

   • Minimizes harmonic effects on the grid and equipment

4. High Reliability and Long Service Life

   • Suitable for continuous industrial duty

   • Low maintenance requirements

5. Flexible Customization Options

   • Configurable for different voltage levels, power ratings, and applications

4. Typical Applications

• ABB medium- and high-power drive systems

• Industrial motor drive and speed control

• Metallurgy and mining drive equipment

• Oil and chemical industry electrical systems

• Cement, paper, and heavy industrial production lines

• Large fans, pumps, and compressor drive systems

5. Installation and Maintenance Notes

1. Verify Parameter Matching

   • Ensure transformer rating and voltage levels match the drive system

2. Proper Installation

   • Ensure proper grounding

   • Maintain sufficient clearance for cooling

3. Environmental Requirements

   • Avoid high humidity, dust, and corrosive environments

   • Ensure adequate ventilation

4. Regular Inspection and Maintenance

   • Periodically check wiring, insulation, and temperature rise

   • Address abnormalities promptly

5. Safe Operation

   • Disconnect power before maintenance

   • Installation and servicing should be performed by qualified personnel
