ABB SA801F 3BDH000011R1 Power Module

• Input Voltage Range: AC 100-240V±10%, 50/60Hz, compatible with power supply standards in different regions worldwide.​

• Output Voltage: DC 24V, output current up to 5A, total output power 120W, meeting the power supply needs of multiple devices.​

• Output Accuracy: Voltage regulation accuracy ±0.5%, ripple coefficient ≤10mV, ensuring stable power supply.​

• Protection Functions: Equipped with overcurrent, overvoltage, short-circuit, and overtemperature protection. Overcurrent protection action current is 6-7A (self-recoverable), and overtemperature protection threshold is ≥70℃.​

• Efficiency: Efficiency ≥88% under typical load, ≥85% under light load (20%), with significant energy-saving effect.​

• Operating Environment: Operating temperature -25℃~70℃, relative humidity 5%-95% (non-condensing), protection class IP20.​

• Dimensions: Width×height×depth approximately 40mm×120mm×100mm, DIN rail mounted, compact structure.​

• Certification Standards: Certified by UL, CE, TÜV, compliant with IEC 60950-1 safety standards.​

• Wide Input Adaptability: Supports 100-240V AC wide voltage input, usable in most industrial scenarios worldwide without adjustment, reducing regional adaptation costs.​

• Highly Stable Output: Low ripple and high-precision DC output provide reliable power for precision equipment such as PLCs, sensors, and small actuators, reducing faults caused by power supply fluctuations.​

• Comprehensive Protection Mechanism: Multiple protection functions respond quickly to abnormal conditions, protecting both the power module itself and downstream equipment from damage due to power supply issues.​

• Efficient and Energy-Saving Design: High conversion efficiency reduces energy loss, which can significantly reduce overall energy consumption in long-term operating industrial systems.​

• Harsh Environment Resistance: Wide temperature operating range and strong anti-electromagnetic interference capability, suitable for high-temperature, dusty industrial environments such as metallurgy and chemical industry.​

• Industrial Automation Control Systems: Provides centralized power supply for PLC modules, I/O units, HMI touch screens, etc., ensuring stable operation of control systems.​

• Process Control Equipment: Supplies power to temperature sensors, solenoid valves and other equipment in auxiliary control loops of chemical reactors and fermenters.​

• Intelligent Manufacturing Production Lines: Provides DC power for small robots, visual inspection equipment, etc., supporting precise control and data transmission of production lines.​

• Energy Monitoring Terminals: Adapts to auxiliary electronic components in photovoltaic inverters and wind power control cabinets, ensuring continuous power supply for monitoring systems.​

• Traffic Signal Systems: Provides stable power for signal control units of rail transit and highways, ensuring reliable operation of signal equipment.​

• During installation, ensure sufficient heat dissipation space between the module and surrounding equipment; avoid stacked installation to prevent overheating.​

• Input and output wiring must be secure to avoid poor contact due to looseness; it is recommended to configure appropriate fuses for the output circuit according to the load current.​

• Before first power-on, check whether the input voltage matches the power supply system to prevent module burnout due to wrong voltage connection.​

• If dust accumulates on the module surface, clean it regularly to maintain good heat dissipation; avoid use in corrosive gas or severe vibration environments.​

• For redundant power supply, multiple modules can be used in parallel (with redundant modules) to improve the reliability of the system power supply.​
