ABB SA801F 3BDH000011R1 Power Module

Product Overview

The ABB SA801F 3BDH000011R1 is a high-performance industrial power module used for driving and controlling medium to large motors and inverters. It features high efficiency, reliability, and thermal protection, providing stable current output and withstanding short-term overload. The SA801F is widely used in industrial automation systems, variable frequency drives, and power electronic equipment to ensure efficient and stable operation.

Technical Specifications

• Model: SA801F

• Order Code: 3BDH000011R1

• Type: Power Module

• Rated Current: 800 A

• Rated Voltage: 1200 V DC

• Module Type: IGBT Power Module

• Switching Frequency: ≤ 5 kHz

• Operating Temperature: –20 °C … +85 °C

• Insulation Voltage: 1500 V

• Package Type: Bolt-mounted

• Protection Features: Overcurrent and overtemperature protection

• Certifications: CE, UL

Advantages & Key Features

1. High power output: Rated 800 A, suitable for high-power drive applications.

2. High efficiency: IGBT technology reduces switching losses and improves energy efficiency.

3. Fast response: High switching frequency suitable for fast dynamic control.

4. Industrial-grade reliability: Temperature and vibration resistant for harsh environments.

5. Multiple protections: Built-in overcurrent and overtemperature protection ensures module and system safety.

6. Modular design: Easy maintenance and replacement, reducing system downtime.

Application Areas

• Medium and large industrial motor drives

• Variable frequency drives and servo drive systems

• Industrial automation control systems

• Power electronics and energy conversion systems

• Renewable energy systems (wind, solar)

Precautions

1. Verify the module rated current and voltage match the system before installation.

2. Follow ABB manuals strictly for wiring to prevent short circuits or poor contact.

3. Ensure good ventilation to avoid high temperature or humidity.

4. Regularly check module temperature and operating status to ensure stable long-term operation.

5. Avoid exceeding rated current and switching frequency to extend module life.
