ABB S802N-C32 High-Performance Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB S802N-C32 is a high-performance miniature circuit breaker (MCB) designed for low-voltage distribution systems to protect circuits and equipment from overloads and short circuits.
It features advanced thermal-magnetic or electronic trip units, fast response, and is suitable for industrial, commercial, and residential applications, combining high reliability with long service life.

2. Main Technical Specifications (Typical)

• Model: S802N-C32

• Product Type: High-Performance Miniature Circuit Breaker (MCB)

• Rated Current: 32 A

• Poles: Single, Double, or Three-pole options

• Trip Characteristic: C type (suitable for general industrial and inductive loads)

• Rated Operational Voltage: AC 230/400 V

• Short-Circuit Breaking Capacity: 10 kA

• Mounting: DIN rail

• Protection Class: IP20

• Operating Temperature Range: -25 ℃ to +60 ℃

• Enclosure Material: Flame-retardant engineering plastic

• Width: 18 mm per pole

3. Key Advantages and Features

1. High-Performance Protection

   • Accurate overload and short-circuit protection for circuit and equipment safety

2. Fast Trip Response

   • C-type trip characteristic suitable for general industrial and inductive loads

   • Thermal-magnetic or electronic trip units react quickly

3. Modular and Space-Saving Design

   • DIN rail mounting, easy to expand and maintain

   • High-density panel layout saves space

4. Reliability and Safety

   • High short-circuit breaking capacity for excellent protection

   • Flame-retardant enclosure for safe operation

5. Easy Operation

   • Clear ON/OFF handle indication

   • Quick reset for maintenance convenience

4. Typical Applications

• Industrial low-voltage distribution systems

• Commercial and residential distribution

• Motor, lighting, and socket circuit protection

• Distribution panels and switchgear

• Power, mining, chemical, and manufacturing industries

5. Installation and Maintenance Notes

1. Rated Current Selection

   • Choose rated current according to circuit load

   • Avoid prolonged overload operation

2. Power-Off Operation

   • Disconnect power before installation or maintenance

3. Installation Environment

   • Avoid high temperature, humidity, and dust

   • Ensure proper ventilation

4. Periodic Inspection

   • Check breaker status and terminal connections

   • Operate handle periodically to maintain mobility

5. Safety Precautions

   • Do not disassemble under live conditions

   • Ensure personnel safety
