ABB S2X80 Molded Case Circuit Breaker

•

• 1. Product Overview

  The ABB S2X80 Molded Case Circuit Breaker (MCCB) is a low-voltage protection and control device designed to protect electrical circuits and equipment from overloads, short circuits, and underloads. It features high breaking capacity, fast response, and high reliability, suitable for industrial, commercial, and building electrical systems.

  The S2X series is compact, easy to install in distribution or control panels, and can be equipped with accessories for remote control, alarms, and interlocking.

  ---

  2. Main Technical Data

  • Model: S2X80

  • Type: Molded Case Circuit Breaker (MCCB)

  • Poles: 3P or 4P

  • Rated current (In): 80 A

  • Rated insulation voltage: 690 V AC

  • Rated operational voltage (Ue): 500 V AC

  • Ultimate short-circuit breaking capacity (Icu): 15 kA (415 V AC)

  • Overload protection: Thermal-magnetic trip

  • Trip characteristics: B, C, D curve selectable

  • Mounting: Panel or DIN rail

  • Protection: IP20 (standard enclosure)

  • Operating temperature: –25 °C to +55 °C

  • Mechanical life: ≥10,000 operations

  • Electrical life: ≥4,000 operations (at rated load)

  • Dimensions: Compact design for distribution systems

  ---

  3. Key Advantages and Features

  1. Reliable protection: Safeguards circuits and equipment against overloads, short circuits, and underloads.

  2. High breaking capacity: Up to 15 kA, suitable for industrial power systems.

  3. Selectable trip characteristics: B, C, D curves for different load protection needs.

  4. Flexible installation: Compact design, panel or rail mountable.

  5. Modular design: Supports accessories for remote control, alarms, and interlocks.

  6. Durable: Long mechanical and electrical life for industrial applications.

  ---

  4. Typical Applications

  • Industrial low-voltage distribution

  • Commercial building power distribution

  • Control and distribution panel protection

  • Machine tools, processing equipment, and automated production lines

  • Motors and heavy-load equipment protection

  • Power generation and energy management systems

  ---

  5. Installation and Operation Notes

  1. Rated parameter match: Ensure breaker rated current, voltage, and breaking capacity meet system requirements.

  2. Correct wiring: Follow wiring diagram carefully and secure all connections.

  3. Environmental conditions: Avoid excessive humidity, dust, and corrosive environments.

  4. Accessory installation: Ensure proper wiring and compatibility for remote control or alarm accessories.

  5. Regular maintenance: Check operation mechanism, contact status, and enclosure integrity for long-term reliability.

•

The structure and details of the product：
