ABB S203-D16 Miniature Circuit Breaker

• 1. Product Overview

  ABB S203-D16 Miniature Circuit Breaker is a three-pole MCB designed for low-voltage distribution systems, providing overload and short-circuit protection. The S203 series ensures fast disconnection of fault currents, protecting electrical equipment and wiring.

  Its compact design supports standard DIN rail mounting and is widely used in residential, commercial, and industrial distribution systems. Type D trip characteristics are suitable for inductive loads such as motors and transformers, providing reliable overcurrent protection.

  ---

  2. Main Technical Data

  General

  • Product type:
    Miniature Circuit Breaker (MCB)

  • Poles:
    3

  • Rated current:
    16 A

  • Trip characteristic:
    Type D (for inductive loads)

  • Rated operating voltage:
    230/400 V AC

  • Rated short-circuit breaking capacity:
    6 kA (IEC/EN standard)

  Electrical Characteristics

  • Operating frequency:
    50/60 Hz

  • Mechanical life:
    ≥ 10,000 operations

  • Electrical life:
    ≥ 4,000 operations (at rated load)

  • Overload protection:
    Thermal-magnetic trip to prevent overload

  • Short-circuit protection:
    Quick magnetic trip to disconnect fault current

  Mechanical & Installation

  • Mounting:
    DIN rail installation

  • Dimensions (mm):
    3 poles × 18 mm width per pole

  • Housing:
    Flame-retardant plastic

  • Operating temperature:
    -5°C to +40°C

  Standards & Certification

  • Compliance:
    IEC/EN 60898-1, IEC/EN 60947-2

  • Protection rating:
    IP20 (front)

  • Application environment:
    Residential, commercial, and industrial low-voltage distribution

  ---

  3. Key Advantages and Features

  1. Reliable overload and short-circuit protection
     Quickly disconnects fault current to protect wiring and equipment.

  2. Suitable for inductive loads
     Type D trip characteristic protects motors, transformers, and similar loads.

  3. Compact design
     Saves space in distribution boards and supports quick DIN rail installation.

  4. High mechanical and electrical life
     Reliable for frequent operations and long-term use.

  5. Easy maintenance
     Modular design allows convenient replacement and expansion.

  6. Compliant with international standards
     IEC/EN certified, ensuring safety and compatibility.

  ---

  4. Typical Applications

  • Residential and commercial distribution systems

  • Small industrial facilities and equipment protection

  • Motor and transformer overload protection

  • Lighting and socket circuit protection

  • Low-voltage distribution boards and control panels

  ---

  5. Installation and Application Notes

  1. Verify current and load compatibility
     Ensure the MCB rated current matches the load to prevent nuisance tripping or overload.

  2. Correct installation orientation
     Mount on standard DIN rail and secure terminals properly.

  3. Environmental requirements
     Avoid high temperature, humidity, and corrosive gas environments.

  4. Periodic inspection
     Test operation and check wiring regularly for long-term safe operation.

  5. Follow standard operating procedures
     Installation and maintenance should comply with IEC/EN standards and local electrical codes.

•
•
•

The structure and details of the product：
