ABB S202M-C2 2CDS272001R0024 Miniature Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• •

  • 1. Product Overview

    The ABB S202M-C2 2CDS272001R0024 Miniature Circuit Breaker (MCB) is a commonly used protective device in low-voltage distribution systems, providing effective protection against overloads and short circuits. Compact and fast-acting, it is suitable for residential, commercial, and light industrial distribution systems.

    ---

    2. Technical Specifications

    • Model: S202M-C2 2CDS272001R0024

    • Device Type: Miniature Circuit Breaker (MCB)

    • Rated Current: 2 A

    • Rated Voltage: AC 230/400 V

    • Poles: 2P (Double Pole)

    • Breaking Capacity: 10 kA

    • Trip Characteristics: C-type (for general and inductive loads)

    • Mounting: DIN rail

    • Operating Temperature: -25 °C to +40 °C

    • Protection Degree: IP20

    • Standards: IEC 60898-1

    • Dimensions: approx. 18 mm × 80 mm × 70 mm

    • Weight: approx. 0.1 kg

    ---

    3. Key Advantages and Features

    • High Reliability: Quickly disconnects overload and short-circuit currents

    • Compact Design: Saves space in distribution panels, easy installation

    • User-Friendly Operation: Manual toggle, intuitive to operate

    • Durable Materials: Temperature and impact resistant, long service life

    • Good Compatibility: Suitable for residential, commercial, and light industrial applications

    ---

    4. Typical Applications

    • Residential and apartment distribution systems

    • Office buildings and commercial power distribution

    • Small industrial equipment protection

    • Distribution panels and branch circuit protection

    • Motor and lighting circuit protection

    ---

    5. Installation and Usage Notes

    • Ensure power is off before installation

    • Verify rated current and breaking capacity match the load

    • Regularly inspect terminals and breaker status

    • Avoid prolonged exposure in humid or corrosive environments

    • Maintain proper ventilation to prevent overheating

  •

The structure and details of the product：
