ABB S202-C6 2CDS252001R0064 Miniature Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB S202-C6 2CDS252001R0064 Miniature Circuit Breaker is a single-pole MCB designed for low-voltage electrical systems, providing protection against overloads and short circuits. The S202 series features high reliability, fast tripping capability, and modular design, allowing easy installation in distribution boxes or control cabinets. It is suitable for residential, commercial, and light industrial applications.

2. Main Technical Parameters (Typical)

Electrical Data

• Model: S202-C6

• Poles: Single-pole (1P)

• Rated current: 6 A

• Rated voltage: AC 230/400 V

• Short-circuit breaking capacity: 6 kA

• Tripping curve: C (suitable for general loads and small motor startup)

Mechanical and Electrical Life

• Mechanical life: ≥ 10,000 operations

• Electrical life: ≥ 4,000 operations

Installation and Dimensions

• Mounting: DIN rail

• Width (1P): 17.5 mm

• Modular design allows combination with other S-series breakers

Environment and Operating Conditions

• Operating temperature: -25°C to +40°C

• Relative humidity: ≤ 95% (non-condensing)

• Suitable for industrial and building environments

Standards and Certifications

• Compliant with IEC/EN 60898-1

• CE certified

• UL 1077 (for some models)

3. Advantages and Features

• Reliable protection: Prevents overloads and short circuits

• Fast tripping: 6 kA breaking capacity ensures electrical safety

• Compact modular design: Allows multi-pole assembly in limited space

• Easy installation and maintenance: Quick DIN rail mounting

• Versatile application: Residential, commercial, and light industrial load protection

4. Typical Applications

• Residential and apartment distribution boxes

• Office buildings and commercial distribution systems

• Small industrial equipment protection

• Automation control cabinets and distribution panels

• Lighting, air conditioning, and small motor protection

5. Application Notes

• Choose rated current according to load (6 A)

• Select the appropriate tripping curve (B, C, D) to match load characteristics

• Ensure DIN rail is securely mounted

• Periodically check breaker operation and terminal tightness

• Do not overload; frequent overloads may reduce service life
