ABB S201U-Z5 Miniature Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB S201U-Z5 is a miniature circuit breaker (MCB) designed for overload and short-circuit protection in low-voltage distribution systems. Compact and reliable, it is suitable for residential, commercial, and light industrial applications. The S201U series provides multiple rated currents and tripping characteristics, allowing flexible system design and protection.

  ---

  2. Technical Specifications

  Parameter	Description
  Model	S201U-Z5
  Type	Miniature Circuit Breaker (MCB)
  Poles	1P (Single-pole)
  Rated Current	5 A
  Tripping Characteristic	Z Type (high sensitivity, fast trip)
  Rated Voltage	230/400 V AC
  Rated Frequency	50/60 Hz
  Breaking Capacity	6 kA (short-circuit current)
  Mounting	35 mm DIN rail
  Standards	IEC/EN 60898-1
  Features	Overload and short-circuit protection, compact design, easy installation

  ---

  3. Key Advantages & Features

  1. High-Sensitivity Protection

     • Z-type tripping characteristic, ideal for cable, precision equipment, and small electronic loads.

  2. Compact Design

     • Saves space in distribution panels, allows multiple installations.

  3. Easy Operation

     • Modular design for easy installation, removal, and maintenance.

  4. High Reliability

     • IEC-compliant, providing stable overload and short-circuit protection.

  5. Wide Application

     • Suitable for residential, commercial, light industrial, and control panel distribution.

  ---

  4. Typical Applications

  • Residential and home distribution protection

  • Commercial low-voltage distribution systems

  • Small industrial control panels and equipment protection

  • Power supply protection for precision instruments and electronics

  • Lighting and small load protection

  ---

  5. Usage Precautions



  • Installation: Must be installed in IEC-compliant distribution systems; ensure DIN rail is securely fixed.

  • Rated Current Selection: Choose rated current according to load to prevent nuisance tripping or insufficient protection.

  • Environmental Conditions: Avoid humidity, dust, corrosive gases, and high-temperature environments.

  • Maintenance: Regularly inspect the breaker and wiring for reliable operation.

  • Usage Limitations: Only for AC low-voltage systems; not suitable for direct DC use or extremely high short-circuit currents.

•
