• • ABB S201M-C6 2CDS271001R0064 Compact S200M Miniature Circuit Breaker — Product Description

    1. Product Overview

    The ABB S201M-C6 is a single-pole miniature circuit breaker from the Compact S200M series. It provides reliable overload and short-circuit protection in low-voltage distribution systems. Compact and easy to operate, it is suitable for residential, commercial, and industrial applications. The modular design allows combination with other S200M breakers for easy expansion and maintenance.

    ---

    2. Technical Specifications

    • Model: S201M-C6 / 2CDS271001R0064

    • Series: Compact S200M

    • Poles: 1P (Single-pole)

    • Rated Current (In): 6 A

    • Ultimate Short-Circuit Breaking Capacity (Icu): 10 kA (400/415 V AC)

    • Operating Voltage (Ue): 230/400 V AC

    • Trip Characteristic: Type C (suitable for general loads such as appliances and lighting)

    • Mounting: DIN rail

    • Mechanical Life: ≥ 10,000 operations

    • Electrical Life: ≥ 4,000 operations

    • Protection Class: IP20

    • Operation: Manual ON/OFF

    • Accessory Compatibility: Auxiliary contacts, alarm contacts, modular expansion accessories

    ---

    3. Features & Advantages

    1. High reliability and safety

       • Accurate trip characteristics for overload and short-circuit protection

       • Complies with IEC/EN 60898-1 standards

    2. Modular and flexible

       • Can be combined with other S200M breakers

       • Easy expansion and maintenance

    3. Compact design

       • Space-saving, ideal for distribution panels

       • Lightweight and easy to handle

    4. Easy installation and operation

       • Quick DIN rail mounting

       • Simple manual operation for easy maintenance

    5. Support for accessories

       • Compatible with alarm and auxiliary contacts for remote monitoring and control

    ---

    4. Typical Applications

    • Residential and commercial low-voltage distribution protection

    • Branch circuit protection in industrial systems

    • Protection of motors, lighting, and general loads

    • Distribution panels, control cabinets, and modular distribution systems

    ---

    5. Precautions

    • Ensure rated current matches the load before installation

    • Installation and wiring must be done with power off

    • Avoid installation in humid or corrosive environments

    • Regularly check terminal connections to ensure proper contact

    • Avoid frequent overloading to extend service life


    •
  •
  •
  •
