ABB S1N125 molded case circuit breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB S1N125 Molded Case Circuit Breaker Technical Documentation

Product Description

The ABB S1N125 is a molded case circuit breaker (MCCB) designed for industrial and commercial electrical protection. It belongs to ABB’s Isomax S series, featuring thermal-magnetic trip protection for overload and short-circuit conditions. With a 125A frame current and multiple pole configurations (3P/4P), it is widely used in motor control, power distribution, and circuit protection applications.

Key Features:

• Compact & robust design – Plastic-insulated housing (IP20) for electrical isolation and durability .

• High breaking capacity – Up to 40kA (230V AC) and 25kA (380/415V AC) for reliable fault interruption .

• Versatile mounting – Supports front/rear wiring and DIN rail/fixed installation .

• Multiple trip units – Configurable with thermal-magnetic (TMD), electronic (PR211/PR212), or residual current (RC221-223) trip units .

Technical Specifications

Applications

1. Motor Protection – Safeguards motors from overload and short circuits in industrial automation .

2. Power Distribution – Used in MCCs (Motor Control Centers) and low-voltage switchgear .

3. Building Electrical Systems – Ensures safety in HVAC, lighting, and emergency power circuits .

4. Renewable Energy – Protects solar/wind power inverters and battery storage systems .

Installation & Safety Notes

1. Wiring Guidelines

   • Use shielded cables for noise immunity; maintain ≥50 cm separation from high-voltage lines .

2. Environmental Conditions

   • Avoid conductive dust and humidity >95%; max ambient temp: +70°C.

3. Maintenance

   • Inspect terminals annually for corrosion; test trip functionality every 6 months .

4. Compliance Standards

   • Meets IEC 60947-2, GB 14048.2 for circuit protection .

The structure and details of the product：

 Please make an inquiry for more models
