ABB RVC8-1/5A Power Factor Controller

Product Overview

The ABB RVC8‑1/5A is a high-performance industrial power factor controller designed to monitor and automatically adjust the power factor of electrical systems. By controlling capacitor banks, it reduces reactive power losses, minimizes network losses, and helps avoid electricity penalties. Suitable for three-phase 380–440 V systems, it is widely used in industrial, commercial, and large building applications for efficient power management.

Technical Specifications

• Model: RVC8‑1/5A

• Type: Power Factor Controller

• Rated Voltage: 380–440 V AC, three-phase

• Rated Current: 5 A

• Power Factor Range: 0.8 lagging to 1.0

• Capacitor Stages: 8-step control

• Switching Mode: Automatic / manual

• Display: LED or LCD for voltage, current, power factor, and capacitor status

• Protection Functions: Over-voltage, under-voltage, overload, short circuit

• Operating Temperature: -10 ~ 55 °C

• Mounting: DIN rail or panel

• Communication Interface: Optional Modbus RTU

• Enclosure Protection: IP20

Key Features & Advantages

• Automatic power factor correction improves system efficiency and reduces reactive losses

• Multi-step capacitor control — 8 capacitor stages for flexible load compensation

• Reliable protection — safeguards against over-voltage, under-voltage, overload, and short circuit

• Easy installation and maintenance — DIN rail or panel mount with intuitive operation

• Clear display — shows voltage, current, and power factor in real-time

• Remote monitoring — Modbus interface allows data acquisition and management

Application Areas

• Industrial plants and large equipment power systems

• Commercial buildings and office building power distribution

• Water treatment plants, HVAC, and pumping station systems

• Utility reactive power management and energy-saving projects

• Automated production lines and heavy industrial equipment

Precautions

1. Ensure supply voltage matches the controller’s rated voltage

2. Install in a well-ventilated environment to avoid high temperature and humidity

3. Regularly inspect capacitor status and wiring terminals

4. Avoid frequent manual switching; use automatic mode primarily

5. Follow electrical safety standards; disconnect power before maintenance

6. Route cables away from high-voltage or high-interference sources
