ABB RPL-03C Control Panel Cable

• Product Overview

  The ABB RPL‑03C is a control panel cable designed for industrial control systems, used for signal and control connections between PLCs, control panels, drives, I/O modules and other field devices. It features strong noise immunity and durability, suitable for long‑term operation in environments with frequent bending, vibration, or electrical noise. It is suitable for digital control, analog signaling and communications.

  ---

  Main Technical Specifications

  • Model: RPL‑03C

  • Product Type: Control Panel Cable

  • Structure: Multi‑core shielded control cable

  • Conductor Material: Oxygen‑free copper (OFC)

  • Core Count / Cross‑Section: Typical multi‑core (e.g., 3, 5, 8 cores); option for 0.5 mm² / 0.75 mm² / 1.0 mm² (actual per specification)

  • Insulation Material: PVC or XLPE

  • Shielding: Aluminum foil + braided copper shield

  • Jacket Material: Oil‑resistant, abrasion‑resistant PVC

  • Rated Voltage: 300 / 500 V

  • Operating Temperature Range: ‑20 ℃ to +75 ℃

  • Interference Immunity: Shielded for improved EMI/RFI resistance

  • Bend Radius: ≥ 6× outer diameter

  • Mounting: Inside control cabinets, trays, cable ducts

  ---

  Key Advantages & Features

  1. Reliable Signal Transmission

     • Oxygen‑free copper with good shielding reduces signal loss and cross‑talk.

  2. Excellent Noise Immunity

     • Foil and braided shielding boost industrial EMI/RFI resistance.

  3. Durable and Rugged

     • Oil and abrasion‑resistant jacket withstands vibration and mechanical wear.

  4. Flexible Installation

     • Multiple core and cross‑section options for flexible wiring needs.

  5. Wide Environmental Range

     • Operates reliably in broad temperature and industrial conditions.

  6. Easy Maintenance

     • Clear core color coding and labeling aid installation and troubleshooting.

  ---

  Typical Applications

  • Control cabinet internal signal wiring

  • PLC to control panel signal link

  • Control input lines for VFDs/servo drives

  • HMI to controller connections

  • I/O module to sensors/actuators wiring

  • Production line equipment control communication

  • Data acquisition & instrument control wiring

  ---

  Installation & Operation Notes

  • Match cores and usage: Confirm needed cores and cross‑section before design.

  • Avoid high‑voltage proximity: Avoid parallel runs with high‑power cables to reduce noise.

  • Proper bend radius and securing: Respect recommended bend radius, avoid tight bends or cable compression.

  • Ground shielding properly: Terminate shield at control cabinet ground for best noise rejection.

  • Environmental protection: Avoid corrosive, moist environments; use protective conduits if needed.

  • Label and organize: Tag cables and bundle neatly for future maintenance.

  • Periodic inspection: Check terminations and jacket condition, replace worn or damaged cable.

•

The structure and details of the product：
