ABB RET630 TBTNAAACAABZEZNBXC Transformer Management Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB RET630 Transformer Management Relay is a digital relay designed for protection, monitoring, and management of power transformers. RET630 provides transformer differential protection, overcurrent protection, overload protection, temperature monitoring, oil level monitoring, alarm recording, and remote communication functions. It offers high reliability, flexible configuration, and intelligent control capabilities, ensuring safe transformer operation and enhancing overall power system stability and reliability.

2. Technical Specifications

• Model: RET630 TBTNAAACAABZEZNBXC

• Product Type: Transformer Management Relay

• Protection Functions: Transformer differential, overcurrent, overload, low oil level, etc.

• Control I/O: Digital and analog inputs/outputs

• Communication Interfaces: IEC 61850, Modbus, DNP3, IEC 60870-5-103

• Power Supply: AC/DC 24–250 V

• Operating Temperature: -25 ℃ to +70 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Degree of Protection: IP54 (front panel), additional enclosure optional

• Display and Operation: Graphical LCD screen, LED indicators, push buttons

• Data Storage: Event recording, fault recording, historical data

• Standards Compliance: IEC 60255 series for power protection

3. Advantages and Features

1. Comprehensive Protection
   Integrates differential, overcurrent, overload, temperature, and oil level monitoring.

2. Intelligent Management
   Remote monitoring, alarm recording, fault diagnostics, and trend analysis improve operational efficiency.

3. High Reliability
   Industrial-grade design suitable for high temperature, humidity, and harsh power environments.

4. Flexible Configuration
   Software-configurable protection logic, alarm thresholds, and communication protocols for different transformer types and networks.

5. Multiple Communication Interfaces
   Supports IEC 61850, Modbus, DNP3, and other mainstream industrial and power communication protocols.

6. Easy Installation and Operation
   Modular design with graphical display for simple operation and maintenance.

4. Typical Applications

• Power transformer protection and monitoring

• Transformer management in power plants and substations

• Distribution transformer protection in industrial and commercial facilities

• High/medium voltage distribution systems

• Energy management and smart grid applications

• OEM transformer protection equipment integration

5. Installation and Usage Notes

1. Verify relay model matches transformer and system voltage/current ratings before installation.

2. Wiring and configuration must be performed by qualified electrical engineers to ensure reliable operation.

3. Avoid installation in high humidity, dust, corrosive, or strong electromagnetic interference environments.

4. Communication interfaces and alarm thresholds must be configured according to system design requirements.

5. Regularly check event records, alarms, and relay status to ensure safe transformer operation.
