ABB RET620 Transformer Management Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB RET620 is a high-performance Transformer Management Relay designed to provide comprehensive protection, monitoring, and control for medium- and high-voltage transformers and associated equipment. The relay integrates multiple protection algorithms, communication interfaces, and diagnostic functions to monitor transformer status, fault conditions, and life parameters, enhancing operational safety, reliability, and economic performance. RET620 supports IEC 61850, Modbus, and other communication protocols, facilitating integration with digital substations and automation platforms.

2. Technical Specifications

• Model: RET620

• Product Type: Transformer Management Relay

• Protection Functions: Overcurrent, Differential, Overload, Ground Fault, Overtemperature protection

• Measurement Functions: Current, Voltage, Power, Power Factor, Transformer Temperature, Oil Temperature, Oil Level

• Communication Interfaces: IEC 61850, Modbus RTU, Modbus TCP/IP

• Display: Color LCD with menu navigation and trend display

• Trip Time: Typical < 30 ms (differential protection)

• Operating Temperature: -25 ℃ to +70 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Degree of Protection: IP54 (front panel)

• Mounting: Panel mount (embedded)

• Certifications: IEC 60255, IEC 61850, CE

• Dimensions (Approx.): H 144 mm × W 144 mm × D 210 mm

3. Advantages & Features

1. Comprehensive Protection
   Integrates overcurrent, differential, ground fault, and temperature protection covering all operational risks of transformers.

2. Real-Time Monitoring and Diagnostics
   Monitors current, voltage, power, transformer temperature, oil level, and other critical parameters, providing early fault warnings.

3. High-Speed Response
   Differential protection trip time typically < 30 ms for fast fault isolation.

4. Multi-Protocol Communication
   Supports IEC 61850, Modbus, and other industrial protocols for system integration and remote monitoring.

5. Intelligent Data Logging
   Built-in event recording and trend analysis support operation, maintenance, and condition assessment.

6. Industrial-Grade Design
   IP54 protection, wide operating temperature range, suitable for harsh environmental conditions.

4. Application Areas

The ABB RET620 Transformer Management Relay is widely used in:

• Power substations and distribution substations

• Industrial facility transformer monitoring and protection

• Smart grids and digital distribution systems

• Power plant transformers and backup transformer protection

• Petrochemical, metallurgical, pharmaceutical, and large industrial facilities

5. Notes & Precautions

1. Disconnect power before installation to avoid electrical hazards and equipment damage.

2. Relay input currents, voltages, and measurement circuits must meet specification requirements.

3. Ensure installation environment is dry, ventilated, and free from corrosive gases.

4. Regularly inspect terminal connections and relay status to ensure proper protection function.

5. Configuration and commissioning should be performed by qualified electrical engineers.

6. When using IEC 61850 or Modbus communication, ensure a stable and properly grounded communication network.
