ABB REJ 525 Ground Fault Relay

1. Product Overview

The ABB REJ 525 Ground Fault Relay is a protection relay for medium and low voltage power systems, designed to detect ground fault currents and provide alarm or trip signals.
It offers high-accuracy detection, fast response, and configurable modes, widely used in power plants, substations, industrial facilities, and distribution networks to protect equipment and ensure personnel safety.

2. Technical Specifications

• Model: REJ 525

• Type: Ground Fault Relay

• Rated Voltage: AC 110–240 V / DC 24–48 V (model dependent)

• Monitoring Current Range: 10 mA – 5 A (adjustable)

• Detection Type: Residual current / Zero-sequence current

• Operating Delay: 0.1 s – 10 s (adjustable)

• Relay Output: 1 or 2 SPDT relay contacts

• Alarm Function: Configurable ground fault alarm, notification, and remote signaling

• Communication Interface: Optional RS485 / Modbus RTU

• Operating Temperature: ‑20 ℃ – +60 ℃

• Mounting: DIN rail

• Protection Class: IP20

• Standards Compliance: IEC 60255-5 / IEC 60255-6

3. Key Advantages & Features

1. High-Accuracy Ground Fault Detection
   Sensitive to low-level ground fault currents for quick detection.

2. Fast Response & Adjustable Delay
   Fast action with configurable delay to optimize protection flexibility.

3. Multi-Functional Output
   Relay outputs can be used for alarm, trip, or remote signaling for layered protection.

4. Multiple Monitoring Modes
   Supports residual current, zero-sequence current, and system unbalance detection.

5. Easy Installation & Integration
   DIN rail mounting for seamless integration with control cabinets and automation systems.

6. Reliable & Durable
   Industrial-grade design with strong interference immunity for long-term operation in harsh environments.

4. Typical Applications

• Low-voltage distribution protection in industrial plants

• Ground fault monitoring in power plants and substations

• Electrical distribution system leakage protection

• Critical infrastructure such as hospitals and data centers

• Oil & gas, mining, and metallurgical industries

5. Installation & Usage Notes

1. System Current Matching
   Ensure relay monitoring current range matches system zero-sequence current to avoid misoperation.

2. Proper Wiring
   Connect CTs, power supply, and relay outputs according to the manual; ensure proper grounding.

3. Set Operating Delay
   Configure delay according to protection requirements to balance safety and false-trip prevention.

4. Environmental Conditions
   Avoid high humidity, corrosive gases, and strong electromagnetic interference.

5. Regular Testing
   Periodically check relay operation and alarm functionality to ensure system reliability.
