ABB PSE170-600-70 Soft Starter

1. Product Overview

The ABB PSE170-600-70 is an industrial-grade Soft Starter designed for smooth starting, stopping, and control of AC motors. It reduces inrush current and mechanical stress during motor startup and shutdown, improving system stability and extending equipment life. It is widely used in industrial automation applications involving motors with high starting torque requirements.

2. Main Technical Specifications (Typical)

• Model: PSE170-600-70

• Product Type: Soft Starter

• Applicable Motor Current: 600 A

• Rated Voltage Range: 380–690 V AC

• Control Type: Three-phase soft start and soft stop

• Starting Modes: Current limiting, time ramp, and user-defined profiles

• Maximum Output Current: 600 A

• Start/Stop Control: Programmable start/stop ramp, delay timers

• Inputs: Digital and analog inputs (depending on configuration)

• Outputs: Relay output, analog output, communication output

• Communication Interfaces: Modbus RTU or fieldbus (optional)

• Protection Functions:

  • Overload protection

  • Under/over voltage protection

  • Overheat protection

  • Phase loss / voltage imbalance protection

  • Output overcurrent protection

• Mounting: Panel or control cabinet installation

• Operating Temperature: –20 ℃ to +50 ℃

• Protection Class: IP20 (for enclosure installation)

• Standards Compliance: IEC/EN 60947-4-2, IEC/EN 61800-5-1

3. Advantages and Features

• Reduced Inrush Current
  Limits motor starting current to preset values to reduce electrical grid impact.

• Extended Mechanical Life
  Smooth start and stop reduce mechanical shock and wear on motor and driven equipment.

• Comprehensive Protection
  Built-in protection algorithms monitor and react to abnormal motor and drive conditions.

• Flexible Programmability
  Adjustable start/stop times, current limits, ramp rates, and delays tailored to application.

• Strong Communication & Integration
  Supports industrial communication protocols for PLC, SCADA, and DCS integration.

• Energy Saving and Lower Maintenance
  Efficient startup reduces energy loss and lowers maintenance requirements.

4. Applications

• Pumping Systems
  Water, wastewater, and fire pumps soft start control.

• Fans and Compressors
  Smooth control for fans, blowers, and compressor motors.

• Conveyor & Production Lines
  Controlled motor start/stop for assembly lines and conveyors.

• Industrial Motor Drives
  General motor control across manufacturing applications.

• HVAC & Ventilation
  Soft start for HVAC fans and large ventilation systems.

• Mining, Chemical & Power Industries
  Repetitive start/stop and high reliability motor control use cases.

5. Precautions for Installation and Use

1. Power Matching
   Ensure the soft starter’s rated current and voltage meet or exceed the motor’s requirements.

2. Correct Wiring
   Follow wiring diagrams for power, control and communication connections.

3. Proper Grounding
   Provide reliable grounding to minimize interference and enhance stability.

4. Suitable Environment
   Install in a dry, clean, and ventilated location free from corrosive gases.

5. Adequate Cooling
   Allow sufficient clearance for airflow and heat dissipation; add fans if needed.

6. Professional Parameter Setup
   Parameter setting should be performed by trained personnel according to application requirements.

7. Routine Inspection
   Periodically inspect terminals, cooling conditions, and logged events to ensure healthy operation.
