ABB PPC322BE1 Analog Input Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB PPC322BE1 is a high-precision analog input module for ABB industrial automation systems. It is used for acquiring and converting voltage, current, or sensor signals and transmitting them to PLCs, DCS, or controllers for precise control and monitoring.

2. Technical Specifications

• Model: PPC322BE1

• Type: Analog Input Module

• Input Channels: Typically 8 channels (refer to datasheet for exact configuration)

• Input Type: Voltage 0–10 V / Current 4–20 mA, selectable

• Resolution: 16-bit A/D conversion

• Sampling Rate: 1–2 ms per channel (configurable)

• Input Impedance: ≥ 10 kΩ (voltage input)

• Isolation Voltage: ≥ 500 V AC (channel to system)

• Accuracy: ±0.1% FS

• Operating Temperature: ‑20 °C to +60 °C

• Storage Temperature: ‑40 °C to +85 °C

• Mounting: DIN rail or backplane

• Protection Rating: IP20

• Standards: IEC/EN 61131-2

3. Key Advantages & Features

1. High-Precision Acquisition – 16-bit resolution ensures accurate signal conversion.

2. Multi-Channel Input – Supports multiple analog inputs to enhance system capability.

3. Isolation Protection – Channel-to-system isolation for safety.

4. Flexible Signal Compatibility – Supports 0–10 V, 4–20 mA and other industrial signals.

5. Modular Design – DIN rail or backplane mounting for easy integration.

6. Industrial Environment Adaptability – Wide temperature range for diverse automation applications.

4. Typical Applications

• Industrial automation control systems

• Data acquisition in PLC/DCS systems

• Motor drives and process control

• Sensor signal acquisition and monitoring

• Factory automation, production lines, and energy management

5. Installation & Usage Notes

1. Signal Matching – Ensure input voltage/current is within module’s rated range.

2. Proper Wiring – Connect analog input terminals according to the manual to avoid miswiring or short circuits.

3. Environmental Conditions – Avoid high humidity, dust, and corrosive environments.

4. Regular Inspection – Check terminals, wiring, and acquisition accuracy periodically.

5. Secure Installation – Mount module firmly to prevent vibration from affecting signal stability.
