ABB PP877K 3BSE069274R1 control panel

1. Product Overview

The ABB PP877K 3BSE069274R1 is a compact operator panel from ABB's Panel 800 series, featuring a high-resolution TFT-LCD display. It is designed for industrial automation systems, providing an intuitive human-machine interface for operators to monitor and control equipment.

2. Technical Specifications

3. Advantages & Features

1. High-Resolution Display: 10.4-inch TFT-LCD screen with 640 × 480 resolution ensures clear graphics and text display.

2. Durable Design: Front panel with IP65 protection rating, suitable for harsh industrial environments, dustproof and waterproof.

3. Multiple Input Methods: Combines touch screen and membrane keyboard for flexible operation.

4. Long Backlight Lifetime: Backlight brightness up to 450 cd/m², with a lifetime of 50,000 hours, reducing maintenance frequency.

5. Compact Installation: Supports VESA 75 × 75 mounting standard, adaptable to various installation needs.

6. Multiple Communication Ports: Provides RS232, RS422/RS485, and other communication ports for easy connection with other devices.

4. Application Fields

• Power Industry: Monitoring and control in power plants and substations.

• Petrochemical Industry: Operator interface for refining and chemical processes.

• Metallurgical Industry: Monitoring of steel production processes.

• Manufacturing Industry: Automation control in production lines.

• Water Treatment: Process control in water and wastewater treatment plants.

• Building Automation: Operator interface in building automation systems.
