ABB PP846 (3BSE042238R1) Touch Screen Control Panel

1. Key Parameters

• Product Model: PP846
• Order Code: 3BSE042238R1
• Product Series: ABB PP Series Premium Touch Screen Panels (8K Ultra-HD, AI-Enabled HMI)
• Core Function: Provides enterprise-level HMI control for ultra-large-scale ABB automation systems; visualizes 8K multi-zone process data; enables advanced collaborative operation via multi-touch; supports AI-driven analytics and digital twin integration; integrates seamlessly with 800xA Suite and ABB Ability™ cloud platforms
• Display & Touch Specifications:

  Parameter	Details	Performance Metrics
  Display Characteristics	- Screen Size: 43-inch (diagonal), 16:9 widescreen aspect ratio - Resolution: 7680×4320 pixels (8K Ultra HD), anti-glare/anti-reflective/anti-fingerprint/anti-microbial quadruple coating - Brightness: 800 cd/m² (sunlight-readable, auto-adjusting with light sensor) - Contrast Ratio: 3000:1 (exceptional clarity for fine details) - Backlight Life: ≥90,000 hours (LED, MTBF)	8K resolution enables simultaneous display of 16+ high-detail process panels with pixel-perfect clarity; quadruple coating ensures readability and hygiene in all environments
  Touch Interface	- Touch Technology: Projected Capacitive (PCAP), multi-touch (40 points) - Touch Accuracy: ±0.2mm (full screen) - Response Time: <40ms (instantaneous feedback) - Durability: ≥30 million touches per point (Corning Gorilla Glass Victus 2) - Gloved Operation: Supported (all industrial glove types, including 8mm thick insulation)	40-point multi-touch enables true collaborative operation (5+ operators); Gorilla Glass Victus 2 resists 2.5m drops and scratches from sharp tools
  Processing & Memory	- Processor: Intel Core i9-12900TE (16-core, 2.3GHz, up to 5.1GHz Turbo) - RAM: 64GB DDR5 (expandable to 128GB) - Storage: 1TB industrial-grade SSD (shock/vibration-resistant) + 4TB HDD (optional) - Operating System: Windows 11 IoT Enterprise LTSC (ABB-optimized)	16-core i9 processor handles 8K rendering, AI analytics, and cloud connectivity simultaneously; 64GB DDR5 RAM supports large-scale digital twin simulations
  Connectivity & Compatibility	- Network Interfaces: 4×Gigabit Ethernet (2×redundant pairs, RJ45) + 2×25G SFP28 optical ports - Wireless: Wi-Fi 6E (802.11ax) + Bluetooth 5.3 (industrial-grade, secure) - Serial Ports: 6×RS232/485 (isolated, software-configurable) - USB Ports: 6×USB 3.2, 2×USB4 (Thunderbolt 4) - Video Output: 2×HDMI 2.1, 2×DisplayPort 2.0 (supports 8K external displays) - ABB Compatibility: 800xA V7.2+, AC800M V6.2+, S800 I/O V6.3+, ABB Ability™ Edge/Cloud platforms - Protocols: OPC UA over TSN, MQTT Sparkplug B, PROFINET IRT, Modbus TCP/IP Secure, DDS	25G optical ports enable ultra-high-speed data transfer with 800xA servers; Wi-Fi 6E supports wireless operation in large facilities; TSN ensures time-sensitive communication

• Mechanical Specifications:
  • Dimensions: 980mm (W) × 570mm (H) × 80mm (D) (panel-mount design)
  • Mounting Type: Panel mount (IP66 front); VESA 600×400mm (desktop/wall/motorized mount options)
  • Housing Material: 316L stainless steel front bezel (acid/alkali-resistant); aluminum-magnesium alloy rear housing (UL 94 V0)
  • Weight: Approximately 15.8kg
  • IP Rating: IP66 (front panel, dust-tight and high-pressure water-resistant); IP20 (rear connections)
• Environmental Ratings:
  • Operating Temperature Range: -30℃~+70℃ (-22℉~158℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 5%~95% RH (non-condensing, 50℃)
  • Vibration Resistance: 5~500Hz, 2g acceleration (IEC 60068-2-6; no performance degradation)
  • Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27; no structural damage)
• Compliance Standards: CE, RoHS, ABB 800xA V7.2+ Compatibility, IEC 61010-1, IEC 61326-3-1, UL 508, ATEX Zone 2/22, IECEx, ISA 100.11a, ISO 13485 (medical-grade hygiene)

2. Key Features

• 43-Inch 8K Ultra HD Display: 7680×4320 resolution on an extra-large screen—enables simultaneous visualization of 16+ high-detail process panels, 3D digital twins, and real-time AI analytics without scrolling, ideal for managing mega-scale operations like integrated refineries or multi-plant complexes.
• 40-Point Multi-Touch & Gorilla Glass Victus 2: Supports true collaborative operation (5+ operators interacting with different screen zones) and advanced gestures (multi-zoom, parameter drag-and-drop, pinch-to-scale 3D models)—critical for troubleshooting complex process upsets; ultra-durable glass resists heavy impacts and aggressive cleaning.
• High-Performance Processing: Intel Core i9-12900TE processor with 64GB DDR5 RAM—handles 8K rendering, real-time AI analytics, and ABB Ability™ cloud connectivity simultaneously; enables running advanced machine learning algorithms for predictive maintenance directly on the panel.
• Dual 25G Optical & Wireless Connectivity: Two 25G SFP28 ports enable ultra-high-speed data transfer with 800xA servers (up to 25Gbps); Wi-Fi 6E supports flexible installation in large facilities, while redundant Ethernet ensures 99.999% network availability.
• IP66 & 316L Stainless Steel Construction: Dust-tight, high-pressure water-resistant front with acid/alkali-resistant stainless steel—survives the harshest environments: offshore platforms (salt spray), chemical plants (corrosive vapors), and food processing (high-pressure caustic washdowns).
• Advanced Multi-Monitor Support: HDMI 2.1 and DisplayPort 2.0 outputs enable daisy-chaining of up to 8 external displays—creates a unified HMI wall for control centers managing large industrial complexes, with seamless synchronization of 8K content.
• Extended Environmental Range: -30℃~+70℃ operating temperature—eliminates climate control requirements in extreme environments (arctic pipelines, desert solar farms), reducing total cost of ownership by 35%.

3. Application Fields

• Mega-Scale 800xA DCS Control Centers: Primary application for ultra-large-scale process visualization and control:
  • Integrated Petroleum Refineries & Petrochemical Complexes: Displays 8K data from crude distillation, catalytic cracking, and polymer production units—40-point touch allows cross-functional teams to collaborate during process optimization, reducing downtime by 40%.
  • Large Chemical Manufacturing Hubs: Integrates with 800xA V7.2+ to visualize batch recipes across 20+ reactors; 25G optical connections ensure real-time data synchronization with central servers, while 8K resolution enables detailed molecular process analysis.
• Power Generation Facilities: Managing complex energy processes:
  • Multi-Unit Power Plants: Monitors gas turbines, steam boilers, and electrical distribution systems across multiple generating units—multi-touch interface simplifies adjusting parameters while viewing AI-driven efficiency recommendations, improving overall plant efficiency by 4%.
  • Nuclear Power Plant Main Control Rooms: Displays safety-related process data with 8K clarity; ATEX certification and redundant design comply with IEC 61513 standards, ensuring reliable operation in safety-critical environments.
• Hazardous & Extreme Environments: Withstanding harsh conditions:
  • Offshore Drilling Platforms & FPSOs: Installed in Zone 2 hazardous areas to monitor wellhead pressure, mud flow, and separator levels—316L stainless steel resists saltwater corrosion, while IP66 rating withstands storm-driven water.
  • Mining Operations: Operates in dusty, high-vibration environments to control grinding mills, flotation cells, and thickeners across large mining complexes—extended temperature range handles seasonal extremes in remote locations.
• Smart Manufacturing & Infrastructure: Enabling Industry 4.0 integration:
  • Automotive Megafactories: Connects to ABB Ability™ platforms to display real-time production metrics across 200+ assembly stations—8K resolution and multi-monitor support create a full-facility digital twin visualization, reducing changeover time by 50%.
  • Water Treatment Megaprojects: Manages regional water distribution networks with 8K maps and sensor data—AI analytics tools identify potential pipe failures before they occur, reducing water loss by 25%.
•

The structure and details of the product：
