ABB PM152 3BSE003643R1 Analog Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Model

ABB PM152 Analog Output Module
Order Code: 3BSE003643R1

Product Overview

The ABB PM152 is an analog output module used in ABB control systems (PLC or DCS), converting digital signals into current or voltage analog outputs for actuators, valves, drives, and other industrial devices. PM152 provides high-precision outputs, supports multiple channels, and is suitable for precision control in process automation systems.

Technical Specifications

• Model: PM152

• Order Code: 3BSE003643R1

• Module Type: Analog Output Module

• Number of Channels: 4 independent analog output channels

• Output Type: Current (0–20 mA / 4–20 mA) or Voltage (0–10 V) selectable

• Resolution: 12-bit

• Accuracy: ±0.1% FS

• Update Rate: 10 ms per channel (depending on system configuration)

• Isolation: Channel-to-channel and system bus isolation

• Operating Voltage: 24 V DC

• Mounting: DIN rail or modular mounting

• Operating Temperature: –20 °C … +60 °C

• Protection Class: IP20

• Standards Compliance: IEC 61131-2, CE

Advantages & Key Features

1. High-precision output: 12-bit resolution ensures accurate analog signal control.

2. Multi-channel support: 4 independent outputs for simultaneous control of multiple actuators or process devices.

3. Flexible output type: Selectable current or voltage output for compatibility with various devices.

4. Electrical isolation: Channel-to-channel and system bus isolation improves safety.

5. Industrial-grade reliability: Resistant to temperature, vibration, and electrical interference for long-term stable operation.

6. Easy installation: DIN rail or modular mounting for convenient integration in control cabinets.

Application Areas

• Industrial automation systems requiring analog control

• Process control (valve, pump, fan regulation)

• Expansion of PLC or DCS analog outputs

• Industrial machinery: robotics, packaging, printing, textile automation

• Analog actuator control in production lines

Precautions

1. Verify module operating voltage and output type before installation to ensure system compatibility.

2. Wiring must comply with system design standards to avoid short circuits or poor contact.

3. Install module in a dry, well-ventilated, non-corrosive environment.

4. Avoid touching live terminals during operation or maintenance for safety.

5. Periodically check module status and output accuracy to ensure normal operation.

6. Do not exceed rated voltage, current, or environmental temperature limits to prevent module damage.
