ABB PCD235A 3BHE0322895R0102 Terminal Unit

•

• 1. Product Overview

  ABB PCD235A 3BHE0322895R0102 is an industrial automation terminal unit designed for control cabinets or rack systems to provide reliable electrical connections, signal distribution, and wiring management. This terminal unit offers robust connection interfaces for analog, digital, power, and communication signals, serving as a foundational wiring module in automation systems.

  ---

  2. Main Technical Specifications (Typical)

  • Model: PCD235A

  • Order No.: 3BHE0322895R0102

  • Product Type: Terminal Unit

  • Applicable Systems: ABB PLC / DCS / automation control cabinets

  • Number of Terminals: Multiple terminal points (depending on configuration)

  • Terminal Type: Screw or spring terminals (model dependent)

  • Wire Cross Section Range: Approx. 0.2–4 mm² (typical; varies by model)

  • Mounting: DIN rail or modular slot installation

  • Rated Voltage: Suitable for low‑voltage industrial control systems

  • Rated Current: Aligned with control signal level requirements

  • Insulation Withstand: Meets industrial control equipment standards

  • Protection Class: IP20 (installed inside control cabinet)

  • Operating Temperature: –25 ℃ to +60 ℃

  • Connection Method: Plug‑in or screw fixed terminal connections

  ---

  3. Advantages and Features

  • Modular Design
    Standard modules integrate seamlessly with ABB control cabinet systems for efficient system assembly.

  • Reliable Electrical Connections
    Multi‑terminal design provides safe connection and distribution for various signal and power lines.

  • Easy Installation and Maintenance
    DIN rail or slot mounting simplifies on‑site installation, wiring, inspection, and servicing.

  • Wide Compatibility
    Interfaces easily with PLCs, DCS, I/O modules, sensors, and other devices.

  • Industrial Environment Ready
    Resistant to vibration and temperature variations, suitable for harsh industrial applications.

  ---

  4. Applications

  • PLC/DCS control cabinet wiring management

  • Factory automation production line electrical connections

  • Industrial mechatronics control and signal acquisition systems

  • Power distribution control systems and field device interfacing

  • Automation test/monitor/control terminal wiring

  ---

  5. Precautions for Installation and Use

  • Verify terminal type and wiring requirements: Ensure that the selected terminal unit matches the system’s wiring standards;

  • Secure terminal connections: Tighten terminal screws to prevent signal loss due to loose connections;

  • Disconnect power before wiring: Always power down control cabinet before wiring or commissioning;

  • Environmental considerations: Avoid exposing the unit to high humidity or corrosive atmospheres;

  • Clear labeling: Use clear labeling for field wiring to facilitate future maintenance;

  • Qualified personnel: Installation, commissioning, and testing should be performed by trained electrical and automation professionals.

•
•
