ABB OESA-F100JT Fusible Disconnect Switch
Item NO.:
OESA-F100JTPayment:
T/TPrice:
$800Product Origin:
SwedenColor:
NEWProduct weight:
3.83KG(0.5KN)Lead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB OESA-F100JT Fusible Disconnect Switch is a robust and reliable device designed for safe isolation and circuit protection in industrial power systems.
It combines a disconnect switch with fuse protection to ensure safe disconnection under short-circuit or overload conditions.
With a compact structure, high breaking capacity, and durable mechanical design, the OESA-F100JT provides dependable performance in motor control centers, automation systems, and industrial power panels.
Provides electrical isolation and load disconnection.
Offers overload and short-circuit protection.
Enables safe load-breaking operations.
Features visual ON/OFF position indication.
Supports optional door interlocks and auxiliary contacts.
| Parameter | Specification |
|---|---|
| Model | OESA-F100JT |
| Type | Fusible Disconnect Switch |
| Rated Current | 100 A |
| Rated Voltage | 600 V AC / 250 V DC |
| Poles | 3-pole (3P) |
| Fuse Type | Class J Fuse |
| Rated Short-Circuit Capacity | 200 kA @ 600 V AC |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Frequency | 50/60 Hz |
| Mechanical Life | ≥10,000 operations |
| Electrical Life | ≥2,000 operations (at rated load) |
| Mounting Type | Panel mount / DIN rail mount |
| Protection Class | IP20 (upgradable to IP30 with cover) |
| Operation | Manual rotary handle (optional extended handle) |
| Terminal Type | Screw or crimp terminal |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Standards Compliance | IEC 60947-3, UL 98, CSA C22.2 No.4 |
| Weight | Approx. 1.5 kg |
Integrated Design – Combines isolation and fuse protection in one compact unit.
High Breaking Capacity – Withstands up to 200 kA short-circuit current.
Clear Visual Indication – Displays ON/OFF status for operational safety.
Durable Construction – Rugged mechanism for extended service life.
Modular Expandability – Compatible with auxiliary contacts and interlock kits.
Flexible Installation – Supports panel or DIN rail mounting for ease of use.
Industrial automation control panels
Motor control centers (MCCs)
Factory and process control systems
Commercial and building power distribution
Power generation and substation systems
Manufacturing and heavy industry applications
Disconnect Power Before Service – Always isolate power before installation or maintenance.
Use Proper Fuse Ratings – Select fuses according to current and voltage requirements.
Check Protection Rating – Ensure the IP rating matches the installation environment.
Tighten Terminals Regularly – Prevent overheating due to loose connections.
Avoid Moisture and Corrosion – Maintain a clean and dry operating environment.
Comply with Standards – Follow IEC and local electrical codes during installation.
The structure and details of the product：
