ABB NXPP-01 Matching Board Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB NXPP-01 Matching Board Module is a key interface module in industrial automation systems and control devices. It is mainly used for internal signal matching, interface adaptation, and power/signal distribution. The module effectively connects different types of controllers and I/O modules, ensuring signal integrity and stable system operation, while enabling modular installation and on-site maintenance.

2. Main Technical Parameters

Electrical Data

• Model: NXPP-01

• Power Supply: 24 V DC (typical)

• Input Interfaces: Digital/analog signal input

• Output Interfaces: Digital/analog signal output

• Maximum Output Current: Typically ≤ 2 A

• Response Time: Fast response for real-time signal matching

• Communication Interface: Compatible with PLC or drive control systems

• Protection Features: Overvoltage, short-circuit, surge protection

Mechanical & Installation

• Dimensions: Standard modular PCB design

• Weight: approx. 0.3–0.6 kg

• Mounting: Inside control cabinet or device slot

• Cooling: Natural convection

• Terminals: Screw-fixed or plug-in type

Environmental & Operating Conditions

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -20°C to +70°C

• Relative Humidity: 5%–95% (non-condensing)

• Protection Level: Suitable for internal cabinet or device installation

• Interference Immunity: Industrial-grade EMI/RFI design

Standards & Certifications

• IEC/EN 61131 series standards

• CE, RoHS certified

3. Advantages and Features

• Optimized signal matching: Connects different controllers and I/O modules effectively

• High-speed response: Ensures real-time control and signal transmission

• High reliability: Overvoltage, short-circuit, surge protection enhances system safety

• Modular design: Easy to install, maintain, and replace

• Wide compatibility: Works with ABB PLCs, drives, and automation devices

• Compact design: Saves control cabinet space and facilitates system integration

4. Typical Applications

• ABB industrial automation control systems

• Signal matching between PLCs and I/O modules

• Industrial robot control systems

• Process control and data acquisition systems

• Motor drives and inverter signal interfaces

• Automation production line control and equipment integration

5. Application Notes

• Ensure I/O port types are compatible with system signals

• Power supply should be stable 24 V DC

• Install in locations with adequate ventilation and cooling

• Avoid continuous operation beyond rated load

• Regularly inspect terminals and board status

• Disconnect power before installation or maintenance for safety

• Avoid exposure to corrosive gases or liquids

The structure and details of the product：

Please make an inquiry for more models
