ABB NRDO-02 Relay Output Terminal Unit

1. Product Overview

• Model Name: NRDO-02 (also written as NRDO02)

• Product Type: Relay Output Terminal Unit / Output Terminal Module

• Manufacturer: ABB

• System Association: Commonly used in ABB Bailey Infi 90 / Net 90 / ABB DCS and I/O architectures as a relay output module.

• Mounting Method: Rail-mounted output terminal unit

The ABB NRDO-02 is a relay output terminal module designed for ABB control and DCS systems. It provides relay contact outputs that convert low-voltage digital control signals into isolated mechanical relay outputs, allowing the control system to drive external loads such as contactors, alarms, and indicator lamps.

2. Technical Specifications

(Values based on public and distributor data; confirm with ABB official documentation before integration.)

3. Features and Advantages

1. Relay-Type Output
   Provides mechanical contact output capable of directly driving various industrial loads such as contactors, alarms, and indicator lights.

2. High Current Switching Capability
   Supports switching currents up to 8 A — suitable for medium-power output control.

3. Optical Isolation
   Each channel is optically isolated, ensuring strong noise immunity and electrical isolation between system and field wiring.

4. Modular Rail-Mount Design
   Compact module structure allows for easy installation and replacement within ABB I/O racks or control cabinets.

5. Seamless System Compatibility
   Fully compatible with ABB DCS systems, including Bailey Infi 90 and Net 90 control platforms.

6. Wide Operating Temperature Range
   Works reliably from –20 °C to +60 °C — suitable for most industrial environments.

7. High Reliability and Proven Design
   A mature ABB module with extensive field use and global industrial support.

4. Typical Applications

• Digital output module for PLC / DCS systems

• Driving alarms, signal lights, and contactors

• Output interface for process control systems

• Energy, petrochemical, metallurgy, water treatment, and power plants

• Integration with ABB Bailey Infi 90 / Net 90 systems

• Remote terminal units and control cabinets in automation systems

5. Installation and Safety Notes

1. Load Matching

   • Ensure the load current does not exceed the rated 8 A per contact.

   • Verify the load type (resistive or inductive) to protect relay life.

2. Voltage Compliance

   • Confirm that load voltage levels (AC / DC) are within the contact limits (up to 250 V AC).

   • Add RC snubbers or surge suppressors for inductive or high-inrush loads.

3. Environmental Conditions

   • Operate within –20 °C to +60 °C.

   • Provide sufficient ventilation to avoid heat accumulation.

4. Wiring and Connections

   • Use appropriately rated cables and ensure tight terminal connections.

   • Keep wiring short and properly grounded to minimize interference.

5. Mounting and Vibration

   • Install on a stable rail or panel to avoid vibration.

   • Regularly inspect mechanical stability and connection integrity.

6. Isolation and Safety

   • Maintain proper creepage and clearance distances.

   • Protect against accidental contact; use covers where necessary.

7. Maintenance and Service Life

   • Periodically check relay contacts, switching life, and insulation resistance.

   • Keep spare modules available for system reliability.

8. Compatibility Check

   • When replacing or upgrading, confirm module model (NRDO-02 or L700712 C) and version compatibility within the ABB I/O architecture.
