ABB NKTU02-015 Terminal Unit Cable

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB NKTU02-015 Terminal Unit Cable is a high-quality industrial cable used for connecting ABB automation systems’ terminal units to control systems or I/O modules, ensuring reliable signal transmission. It features durable conductors and sheath materials for long-term stable operation and strong interference immunity, widely used in industrial automation, factory equipment, and process control systems.

2. Technical Specifications

• Model: NKTU02-015

• Product Type: Terminal Unit Cable

• Conductor Material: Stranded copper wire

• Cross-Section Area: 0.34 mm²

• Number of Conductors: 15 cores

• Insulation Material: PVC

• Sheath Material: PVC, wear-resistant, oil-resistant, corrosion-resistant

• Rated Voltage: 300 V

• Operating Temperature: –20 ℃ to +70 ℃

• Minimum Bending Radius: 10 × cable diameter

• Standard Length: Customizable (commonly 5 m, 10 m)

• Protection Class: IP20 (connected state)

• Standards: CE / UL / IEC 60228

3. Advantages and Features

1. High-Reliability Transmission
   Stranded copper conductors ensure stable signal and strong interference immunity.

2. Durable Sheath
   PVC sheath is oil-resistant, wear-resistant, and corrosion-resistant, suitable for industrial environments.

3. Flexible Installation
   Small bending radius allows easy routing inside control cabinets and equipment.

4. Multi-Core Design
   15-core structure allows simultaneous multi-signal transmission.

5. Good Compatibility
   Fully compatible with ABB NKTU series terminal units and control modules.

4. Applications

• Signal connection in industrial automation control systems

• Wiring for PLC / DCS system I/O modules

• Robotics and automated production lines

• Factory equipment monitoring and control circuits

• Packaging, printing, and chemical machinery control systems

5. Installation and Usage Notes

1. Ensure cable cores, length, and terminals are compatible before installation.

2. Perform wiring and installation with power disconnected.

3. Avoid direct use in high-temperature, high-humidity, mechanically abrasive, or chemically corrosive environments.

4. Regularly check terminals and cable sheaths to ensure long-term reliable operation.

5. Do not modify or strip the cable sheath to avoid affecting signal transmission.
