ABB NDSM05 discrete output module

Item NO.:
NDSM05
Payment:
T/T
Price:
$1200
Product Origin:
Sweden
Color:
NEW
Lead Time:
In stock

ABB NDSM05 Discrete Output Module

ABB NDSM05 is a rugged discrete output module designed for ABB Symphony Plus and AC 800M industrial automation systems. It specializes in converting digital control signals from upper-level controllers into drive signals for field actuators (e.g., relays, solenoid valves, indicator lights), serving as a core execution component in industrial discrete control loops—ideal for process, power, and manufacturing sectors requiring reliable on/off control of field devices.

Core Product Features

High-Density Output Channels: Integrates 16 independent discrete output channels, all supporting 24V DC low-power load drive. Each channel operates independently, enabling simultaneous control of multiple actuators without cross-interference.
Dual-Level Protection: Each output channel features overcurrent protection (1A per channel, auto-recovery after fault removal) to prevent burnout from load short circuits; the module also has ESD protection (IEC 61000-4-2, ±8kV contact discharge) to resist static damage during installation/maintenance.
Visual Status & Diagnostics: Equipped with per-channel LED indicators (red for "ON", off for "OFF") for intuitive status checks; module-level fault LEDs (power, communication) and open-circuit detection for output wiring. Fault information is transmitted to the controller via the system bus for remote troubleshooting.

Key Parameters

Parameter Category	Specifications
Output Channels	16 channels (isolated between channels; 2.5kV AC isolation from backplane)
Output Signal	24V DC (18-30V DC); max current 1A per channel, total module current ≤8A
Switching Performance	Turn-on time ≤1ms, turn-off time ≤0.5ms; supports 100,000+ switching cycles (mechanical life)
Load Compatibility	Resistive, inductive, and capacitive loads (e.g., 24V DC relays, indicator lights, small solenoid valves)
Power Supply	24V DC (18-30V DC); power consumption ≤6W (full load)
Environmental Adaptability	Operating temperature: -40°C to +70°C; humidity: 5%-95% (non-condensing); protection grade IP20
Mechanical Specs	100mm×80mm×25mm; DIN rail-mounted (35mm standard); compatible with ABB standard I/O racks

Core Advantages

High Reliability: Uses industrial-grade components (e.g., anti-oxidation terminal blocks, high-temperature capacitors) and multi-layer PCB design to reduce electromagnetic interference (EMI) from adjacent power circuits—stable for long-term operation in harsh industrial environments (e.g., chemical plants, steel mills).
Space Efficiency: 16 channels integrated in a compact form factor (100mm×80mm×25mm) reduces control cabinet space usage by 30% compared to low-density modules, ideal for systems with dense discrete output requirements.
Seamless ABB Integration: Native compatibility with ABB controllers (e.g., PM864, AC 800M) via the PROFIbus DP module bus. Configurable through ABB Control Builder M software, supporting online adjustment of output logic (e.g., normally open/normally closed) without system shutdown.

Typical Applications

Process Industry: In chemical plants, controls solenoid valves for pipeline media switching and agitator start/stop relays, executing on/off commands from the DCS to maintain stable production sequences.
Power Plant Auxiliaries: Drives indicator lights (e.g., "pump running", "valve open") and small fan relays in boiler auxiliary systems, providing visual status feedback and ensuring timely response to controller commands.
Manufacturing Automation: In automotive assembly lines, controls robotic gripper solenoid valves and station lock cylinders, coordinating with the main PLC to realize sequential production operations (e.g., part clamping, station transfer).

Usage Precautions

Wiring: Use 0.5-2.5mm² copper wires for output terminals; ensure correct polarity (positive/negative) to avoid short circuits. For inductive loads (e.g., relays), add freewheeling diodes in parallel with the load to suppress voltage spikes during turn-off.
Load Management: Do not exceed the 1A per-channel or 8A total-module current limits—use external contactors for loads >1A (e.g., large motors) to prevent module damage.
Maintenance: Regularly check LED indicators to confirm channel status; clean dust from module vents every 3 months to prevent overheating. Test output channels annually using a multimeter to verify voltage output and protection circuit functionality. Replace the module if outputs frequently trip (indicates internal overcurrent protection failure).
