  • ABB NDSM04 Digital Slave Module

    1. Product Description

    The ABB NDSM04 is a digital slave module designed for the Bailey Network 90 control system, part number 6635582B1.
    The module provides 8 independent pulse input channels with a frequency range of 0–50 kHz.
    It is used to collect pulse signals from field devices such as flow meters and counters, and transmit data to the main control system.
    The module features rack mounting, making it suitable for industrial automation control systems.

    ---

    2. Technical Specifications

    Item	Specification
    Model	NDSM04
    Part Number	6635582B1
    Input Channels	8 pulse input channels
    Frequency Range	0–50 kHz
    Input Voltage	+5 VDC (1.5 A) or +24 VDC (80 mA)
    Mounting	Rack mount
    Dimensions (L × W × H)	Approx. 12.7 cm × 5.1 cm × 12.7 cm
    Weight	Approx. 0.1 kg
    Compatible Systems	Bailey Network 90, Symphony, Infi90

    ---

    3. Features & Advantages

    • High Compatibility: Compatible with ABB Bailey Network 90, Symphony, and Infi90 control systems, ensuring flexible system integration.

    • Multi-Channel Input: Provides 8 independent pulse input channels for various field device data collection.

    • Wide Frequency Range: Supports 0–50 kHz to meet different application requirements.

    • Flexible Power Options: Supports +5 VDC or +24 VDC input, suitable for different power environments.

    • Compact Design: Rack-mount design with a small footprint saves control cabinet space and facilitates installation and maintenance.

    ---

    4. Application Fields

    • Industrial automation: Pulse signal collection in production lines and automated equipment.

    • Water treatment systems: Data acquisition and monitoring from flow meters and counters.

    • Energy management: Data collection for power metering and monitoring systems.

    • Building management systems: Monitoring and management of devices in intelligent buildings.

    • Process control systems: Collects pulse signals from field devices for real-time process monitoring.

    ---

    5. Precautions

    1. Installation Requirements: Ensure the installation location meets device specifications and does not interfere with normal operation.

    2. Electrical Connections: Disconnect power before installation or maintenance to ensure safety.

    3. Environmental Conditions: Install in a dry, well-ventilated environment; avoid high temperature and humidity.

    4. Regular Maintenance: Periodically check device operation to ensure stable system performance.

  •

The structure and details of the product：
