ABB NDCU-22 drive control unit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB NDCU-22 is an industrial Drive Control Unit used for controlling AC/DC motor drive systems. It provides precise speed, torque, and braking control, and integrates seamlessly with inverters, brake units, and higher-level control systems. NDCU-22 is designed for reliability, fast response, and easy installation, making it a key component in industrial automation, machinery, and power drive applications.

2. Technical Specifications

• Model: NDCU-22

• Type: Drive Control Unit

• Application: AC/DC motor drive control

• Interfaces:

  • Digital Inputs/Outputs (DI/DO)

  • Analog Inputs/Outputs (AI/AO)

  • Communication: CAN / RS485 / Modbus (verify specific variant)

• Control Functions:

  • Speed control

  • Torque control

  • Start/Stop control

  • Brake control (with brake unit)

• Power Supply: 24 V DC (typical)

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -20°C to +70°C

• Humidity Range: 5% – 95% (non-condensing)

• Mounting: DIN rail or cabinet panel

• Diagnostics: LED status indicators, fault output

• Standards: CE / IEC 61800 series

3. Advantages & Features

1. High-performance control

   • Provides precise speed, torque, and braking control for system stability and fast response.

2. Versatile interfaces

   • Supports multiple analog/digital I/O and communication protocols for easy PLC/DCS integration.

3. High reliability

   • Industrial-grade design, resistant to temperature, interference, and harsh conditions.

4. Easy installation and maintenance

   • Modular design, DIN rail and panel mounting, convenient for service.

5. Status monitoring

   • LED indicators and fault output allow quick diagnostics and maintenance.

6. Strong compatibility

   • Seamlessly integrates with ABB drives, brake units, sensors, and control systems.

4. Application Areas

• Industrial automation production line drive control

• Elevators, cranes, and conveyor systems

• Fans, pumps, and motor drives

• Heavy machinery and material handling equipment

• PLC / DCS system integration

• Manufacturing, steel, mining, and water treatment industries

5. Precautions & Recommendations

1. Power supply

   • Ensure stable 24 V DC to avoid control errors or equipment damage.

2. Environmental conditions

   • Install in a dry, ventilated, and non-corrosive cabinet.

3. Wiring

   • Follow product manual for correct wiring to prevent short circuits or incorrect operation.

4. ESD protection

   • Observe anti-static precautions during installation and maintenance.

5. Regular inspection

   • Check LED status and connector reliability to ensure proper operation.

6. System compatibility

   • Use with ABB drives and brake units; non-compatible equipment may affect control performance.
