ABB NBTM01 bus transmission module

• • • Product Overview

      The ABB NBTM01 is a high-performance Bus Transmission Module designed for ABB Distributed Control Systems (DCS) and industrial automation networks.
      It enables high-speed data communication between control system modules, ensuring stable and reliable data transfer.
      The NBTM01 supports multiple industrial bus protocols, features a modular design, and has built-in self-diagnostics for long-term stable operation in complex industrial environments.

      ---

      Key Technical Specifications

      Parameter	Description
      Model	NBTM01
      Module Type	Bus Transmission Module
      Communication Interfaces	RS-485, RS-232, Ethernet (optional)
      Supported Protocols	Modbus RTU, PROFIBUS, EtherNet/IP, ABB DCS bus protocols
      Data Rate	9.6 kbps to 12 Mbps (depending on interface and protocol)
      Operating Voltage	24 V DC
      Power Consumption	<5 W
      Operating Temperature	-25°C to +70°C
      Storage Temperature	-40°C to +85°C
      Protection Class	IP20 (for cabinet installation)
      Dimensions	120 × 80 × 30 mm
      Weight	Approx. 0.35 kg
      Certifications	CE, RoHS

      ---

      Advantages & Features

      1. High-Speed Data Transmission
         Supports real-time data exchange, ensuring efficient operation of industrial automation systems.

      2. Multi-Bus Protocol Compatibility
         Supports Modbus, PROFIBUS, EtherNet/IP, and ABB DCS protocols for strong compatibility.

      3. Modular Design
         Plug-and-play design allows easy installation, maintenance, and system expansion.

      4. High Reliability
         Built-in self-diagnostics monitor module and bus status to enhance system safety.

      5. Strong Interference Immunity
         Optimized circuitry ensures stable operation in complex industrial environments.

      ---

      Applications



      • High-speed communication between modules in ABB Distributed Control Systems (DCS)

      • Industrial automation bus network expansion

      • Automated production line monitoring and data transfer

      • Network communication in power, petrochemical, chemical, and water treatment systems

      • Remote monitoring and process data management in factories
