ABB NAOM01 analog output module

• • • • • • • • Product Overview

                The ABB NAOM01 is a high-performance Analog Output Module designed for ABB Distributed Control Systems (DCS) and industrial automation systems.
                It converts digital control signals into analog outputs (current or voltage) for precise control of actuators, valves, motors, and other devices.
                The NAOM01 features high accuracy, stability, and built-in self-diagnostics for reliable long-term operation in industrial environments.

                ---

                Key Technical Specifications

                Parameter	Description
                Model	NAOM01
                Module Type	Analog Output Module
                Output Type	Current output 4–20 mA or Voltage output 0–10 V (optional)
                Output Channels	2–4 channels (optional)
                Load Capacity	Current output: 500 Ω max; Voltage output: 10 mA max
                Accuracy	±0.1% FS
                Response Time	<5 ms
                Communication Interfaces	RS-485, RS-232, Ethernet (optional)
                Operating Voltage	24 V DC
                Power Consumption	<5 W
                Operating Temperature	-25°C to +70°C
                Storage Temperature	-40°C to +85°C
                Protection Class	IP20 (for cabinet installation)
                Dimensions	120 × 80 × 30 mm
                Weight	Approx. 0.4 kg
                Certifications	CE, RoHS

                ---

                Advantages & Features

                1. High-Precision Analog Output
                   Supports current or voltage output with high accuracy for precise control systems.

                2. Fast Response
                   Short response time, suitable for fast dynamic control applications.

                3. Modular Design
                   Plug-and-play for easy installation, maintenance, and system expansion.

                4. High Reliability
                   Built-in self-diagnostics ensure stable and reliable output signals.

                5. Multiple Output Channels
                   Supports 2–4 channels for controlling multiple actuators simultaneously.

                6. Strong Interference Immunity
                   Optimized circuitry ensures stable operation in complex industrial environments.

                ---

                Applications

                • Analog output expansion in ABB Distributed Control Systems (DCS)

                • Actuator control in industrial automation systems

                • Analog control in power, petrochemical, chemical, and water treatment systems

                • Automated production line control and monitoring

                • Precise control of valves, motors, and regulating devices

              •

The structure and details of the product：
