ABB MUI-01 3AFE61320946P0001 Interface Module
Item NO.:
MUI-01 3AFE61320946PPayment:
T/TPrice:
$2000Product Origin:
swedenColor:
SEWProduct weight:
0.94KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB MUI-01 3AFE61320946P0001 Measurement Unit Interface Module is a vital component in ABB’s drive and control systems, designed to handle signal acquisition, data communication, and analog/digital interfacing between control and measurement units.
It is commonly used in ABB ACS600, ACS800, and ACS880 variable frequency drives and other ABB automation platforms.
With its high-precision signal conversion, strong noise immunity, and robust isolation design, the MUI-01 ensures safe and reliable performance in demanding industrial environments.
| Parameter | Specification |
|---|---|
| Model | MUI-01 |
| Part Number | 3AFE61320946P0001 |
| Type | Measurement Unit Interface Module |
| Main Functions | Analog signal input/output, communication, and status monitoring |
| Compatible Systems | ABB ACS Series Drives and DCS Control Platforms |
| Power Supply | 24 V DC (±10%) |
| Power Consumption | ≤ 5 W |
| Analog Inputs | 4 channels (0–10 V / 4–20 mA configurable) |
| Analog Outputs | 2 channels (0–10 V) |
| Digital Inputs | 6 isolated inputs (24 V DC) |
| Digital Outputs | 4 transistor outputs (max 0.5 A each) |
| Communication Interface | Internal bus / RS-485 / Modbus (depending on configuration) |
| Isolation | Optical isolation between channels and bus system |
| Signal Accuracy | ±0.1% F.S. |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5%–95%, non-condensing |
| Protection Class | IP20 (for control cabinet installation) |
| Mounting | Plug-in module for drive rack or chassis |
| Indicators | LED for power, communication, and fault status |
| Dimensions | Approx. 160 × 100 × 25 mm |
| Weight | Approx. 0.2 kg |
High signal accuracy – Precise analog and digital data acquisition ensures control reliability.
Electrical isolation – Prevents noise coupling and signal interference.
Modular design – Simplifies replacement and system upgrades.
Strong EMC protection – Designed for harsh industrial electromagnetic environments.
Status indication – LED lights for power, communication, and fault monitoring.
Wide compatibility – Integrates seamlessly with ABB drives and DCS systems.
Industrial automation and process control
Motor drive and frequency inverter systems
Measurement and monitoring applications
Power generation and energy management
Petrochemical and metallurgical plants
Water treatment and building automation
Environment – Install inside a dry, clean, and ventilated control cabinet.
Power Supply – Use a stable 24 V DC ±10% supply with surge protection.
ESD Protection – Wear an anti-static wrist strap during installation.
Signal Wiring – Separate analog and digital signal cables; use shielded wires.
Communication – Use shielded twisted-pair RS-485 or Modbus cables.
Maintenance – Regularly inspect terminal connections and LED indicators.
