ABB MOD600ARTD4 Analog Input Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB MOD600ARTD4 is a high-precision analog input module for ABB 600 series DCS/PLC systems. It is used to acquire analog signals (voltage, current, or thermocouple), converting them into digital signals for control systems. The module is suitable for process automation, factory control, and energy management systems, offering multi-channel high-accuracy acquisition for reliable data and stable system performance.

2. Technical Specifications

• Model: MOD600ARTD4

• Brand: ABB

• Type: Analog Input Module

• Input Types: Voltage, Current, Thermocouple

• Number of Channels: 4

• Input Ranges:

  • Voltage: 0–10 V DC

  • Current: 0/4–20 mA

  • Thermocouples: Supports multiple types (K, J, T, E, etc.)

• Resolution: 16-bit

• Sampling Rate: Configurable, typically 10–20 ms per channel

• Isolation Voltage: ≥ 500 V between power and input

• Operating Temperature: ‑20 °C to +70 °C; Storage: ‑40 °C to +85 °C

• Mounting: DIN rail or module card installation

• Communication Interface: Compatible with MOD600 series bus

• Protection: Overvoltage and short-circuit protection

• Applications: Process automation, industrial control, energy management, data acquisition

3. Key Advantages & Features

1. High-Precision Acquisition – 16-bit resolution ensures accurate analog-to-digital conversion for precise control.

2. Multi-Channel Input – 4 independent channels save space and reduce wiring complexity.

3. Wide Input Compatibility – Supports voltage, current, and thermocouple inputs for various industrial sensors.

4. High Reliability – Overvoltage, short-circuit protection, and high insulation design ensure long-term stability.

5. Easy Integration – Directly compatible with MOD600 series DCS/PLC bus for simplified system integration.

6. Industrial Environment Ready – Operates reliably across wide temperature, humidity, and electromagnetic environments.

4. Typical Applications

• Industrial process automation and monitoring systems

• Oil & gas, power generation, and energy management

• Monitoring temperature, pressure, flow, and other process variables

• Data acquisition and remote monitoring systems

• HVAC systems and building environment control

5. Installation & Usage Notes

1. Input Signal Matching – Ensure input signal type matches module configuration to avoid damage.

2. Wiring Practices – Use shielded cables and proper grounding to reduce electromagnetic interference.

3. Environmental Conditions – Avoid excessive humidity, dust, and corrosive gases.

4. Temperature Control – Operate within specified temperature range to maintain data accuracy.

5. Regular Inspection – Check connections and signal stability to ensure long-term reliability.
