ABB LF1005-S/SP16 Current Transducer
Item NO.:
LF1005-S/SP16Payment:
T/TPrice:
$680Color:
NEWProduct weight:
0.45KGLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB LF1005-S/SP16 is a high-precision closed-loop Hall effect current transducer designed to measure DC, AC, and pulsed currents. It provides safe galvanic isolation between the primary circuit and the control system while delivering a stable analog output for monitoring, feedback, and protection.
It is especially suitable for high-current applications such as drives, inverters, and power electronics.
| Item | Specification |
|---|---|
| Model | LF1005-S/SP16 |
| Sensor Type | Closed-loop Hall effect current transducer |
| Nominal Primary Current | 1000 A RMS |
| Measuring Range | 0 to ±2000 A (typical) |
| Measured Current Type | AC / DC / Pulsed |
| Accuracy | ≤ ±0.5% |
| Linearity Error | ≤ ±0.1% |
| Response Time | < 1 µs |
| Bandwidth | Wide bandwidth for fast current changes |
| Supply Voltage | ±15 to ±24 V DC or 12 to 30 V DC (version dependent) |
| Output | Proportional analog signal |
| Isolation Voltage | ≥ 3 kV RMS (50 Hz, 1 min) |
| Operating Temperature | -40 °C to +85 °C |
| Mounting | Busbar or panel mounting |
| Protection Class | IP20 |
| Design | Industrial-grade, low drift, high stability |
High accuracy and excellent linearity
Very fast dynamic response
Wide current measurement range
High electrical isolation for safety
Rugged industrial design
Easy integration into PLC, DCS, and drive systems
Variable frequency drives (VFD)
Motor control systems
Industrial automation
UPS and power supply monitoring
Power electronics and converters
Energy and distribution systems
Verify the supply voltage before installation.
Ensure correct wiring and polarity.
Mount the sensor securely and away from strong magnetic fields.
Ensure firm connection of the high-current conductor.
Perform periodic inspections to maintain accuracy and safety.
The structure and details of the product：
