ABB LD800HSE 3BDH000320R02 fieldbus linking device

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB LD800HSE 3BDH000320R02 Fieldbus Linking Device – Product Information

1. Product Overview

The ABB LD800HSE (3BDH000320R02) is a high-performance fieldbus linking device used to connect industrial devices to control systems, enabling data exchange over PROFIBUS or other industrial fieldbus networks.
It provides a reliable communication interface within automation systems, ensuring efficient and stable data transmission between field devices and controllers.

2. Technical Specifications

• Model: LD800HSE

• ABB Part Number: 3BDH000320R02

• Type: Fieldbus Linking Device

• Communication Protocol: PROFIBUS DP / HSE

• Network Interface: Ethernet / RS-485 optional

• Data Transfer Rate: Up to 12 Mbps (PROFIBUS)

• Maximum Connected Nodes: Up to 32 PROFIBUS slave devices

• Operating Temperature: -25 ℃ to +60 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Humidity: 5% to 95%, non-condensing

• Supply Voltage: 24 V DC

• Power Consumption: Approx. 5 W

• Protection Class: IP20

• Mounting: DIN rail or panel mount

• Certifications: CE, UL, RoHS

3. Features and Advantages

1. Reliable communication – Supports PROFIBUS DP / HSE industrial standards for stable data transmission.

2. Flexible network expansion – Connects multiple slave devices for scalable system networking.

3. High-speed data transfer – Up to 12 Mbps communication ensures real-time control.

4. Industrial-grade design – Strong interference immunity suitable for harsh industrial environments.

5. Easy installation and maintenance – DIN rail or panel mount simplifies system integration.

6. High compatibility – Works seamlessly with ABB automation devices and standard PROFIBUS networks.

4. Application Areas

• ABB industrial automation control systems

• Distributed Control Systems (DCS)

• Process control and monitoring systems

• Factory automation production lines

• Power and energy management systems

• Smart building and industrial communication networks

5. Precautions

1. Installation and wiring must be performed by qualified personnel.

2. Disconnect power before wiring to prevent electric shock or device damage.

3. Do not exceed rated voltage, current, or temperature limits.

4. Regularly check interfaces and terminals for reliable contact.

5. Use protective measures in high humidity, dusty, or corrosive environments.

6. Follow ABB recommended procedures for maintenance and system upgrades.
