ABB JCU-11 3AUA0000047068 Drive Control Unit

Item NO.:
JCU-11 3AUA000004706
Payment:
T/T
Price:
$3450
Product Origin:
Germany
Color:
NEW
Goods stock:
2
Product weight:
1.18KG
Lead Time:
in stock

- - - - ABB JCU-11 (3AUA0000047068) Drive Control Unit

        The ABB JCU-11 (3AUA0000047068) is a Drive Control Unit (JCU = Joint Control Unit) used in ABB ACS800 series frequency converters (VFD drives). It is the main control “brain board” of the drive, responsible for controlling power modules, I/O signals, and drive operation logic.

        Key Specifications

        Model: JCU-11

        Order Code: 3AUA0000047068

        Brand: ABB

        Series: ACS800 Drive System

        Type: Drive Control Unit (VFD Control Board)

        Function:

        Controls inverter switching (IGBT gate control)

        Processes start/stop commands

        Handles speed reference and feedback

        Manages protection and fault logic

        Communication (typical ACS800 system):

        Modbus / Fieldbus adapters (external modules)

        Drive-to-PC service interface

        Power Supply: Supplied from drive internal DC/aux supply

        Mounting: Installed inside ACS800 drive frame

        Weight: ~0.5–0.7 kg (typical listings)

        What it does (simple explanation)

        Control Signal (PLC / HMI / terminals)
        ↓
        JCU-11 Control Unit
        ↓
        Processes logic + protection
        ↓
        IGBT Power Stage
        ↓
        Motor speed control (AC output)

        It is the core control board inside the ABB drive, not an external module.

        Main Functions

        Controls motor speed and torque

        Processes analog/digital input signals

        Sends gating signals to power IGBT modules

        Executes drive protection (overcurrent, overvoltage, overheating)

        Handles fault diagnostics and trip conditions

        Manages start/stop and direction control

        Key Features

        Central control board for ACS800 drive system

        High-speed real-time motor control

        Integrated protection and fault monitoring

        Supports multiple fieldbus communication options (via add-on modules)

        Reliable industrial-grade control electronics

        Designed for heavy-duty drive applications

        Applications

        Industrial AC motor drives

        Pumps and compressors

        Conveyors and material handling systems

        Paper, steel, mining industries

        Process automation systems

        High-power industrial VFD systems
