ABB IPFAN12 high-performance fan module

1. Product Overview

The ABB IPFAN12 is a high-performance fan module from the ABB Harmony series, designed for industrial automation and process control systems. It provides efficient cooling for rack-mounted control and power modules through high airflow, ensuring stable operation over the long term.

2. Technical Specifications

3. Advantages & Features

• High-Efficiency Cooling: Airflow up to 150 CFM ensures rapid temperature reduction in rack modules.

• Low Noise Design: Optimized fan blades and structure keep noise levels ≤55 dB.

• Energy Efficient: Low power consumption and reliable operation reduce system energy usage.

• Modular Installation: Can be directly installed in Harmony system racks or chassis for easy maintenance.

• Durability: High-quality fan and bearing materials ensure long-term stable operation.

4. Application Fields

• Industrial Automation: Cooling for rack-mounted control systems and field I/O modules.

• Process Control: Cooling for control cabinets in chemical, oil, and gas industries.

• Power Systems: Cooling of power monitoring and automation equipment racks.

• Building Automation: Heat management for control cabinets and rack-mounted devices.

5. Usage Precautions

1. Environmental Requirements: Install in dry, ventilated environments, avoiding high temperature, humidity, or corrosive gases.

2. Power Connection: Ensure 24 VDC power wiring is correct to avoid short circuits or fan damage.

3. Regular Cleaning: Periodically clean fans and heat sinks to maintain effective cooling.

4. Protective Measures: Avoid contact with fan blades during operation or maintenance to prevent injury.
