ABB INLIM03 loop interface module

Product Overview

The ABB INLIM03 Loop Interface Module is a critical interface module in industrial automation systems, designed to transmit signals and data between controllers and field loop devices.
It supports multiple analog and digital I/O signals, converting field device signals into standardized signals recognizable by the control system for precise monitoring and control.
Suitable for industrial applications requiring reliable interface conversion, signal isolation, and multi-loop management.

Technical Specifications

Model: INLIM03
Module Type: Loop Interface Module
Signal Types: Analog input/output, Digital input/output
Input Range: 0–10 V / 4–20 mA (optional)
Output Range: 0–10 V / 4–20 mA (optional)
Resolution: 16-bit
Response Time: < 10 ms
Interface Types: RS485 / Profibus / Ethernet
Compatibility: Compatible with ABB series controllers and I/O modules
Supply Voltage: 24 V DC
Power Consumption: < 5 W
Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
Humidity: 5%–95%, non-condensing
Protection Rating: IP20
Mounting: DIN rail or chassis
Dimensions: approx. 120 × 90 × 35 mm
Weight: approx. 0.4 kg
Certifications: CE / UL / RoHS

Features & Advantages

1. Reliable Interface – Provides precise signal conversion and isolation to ensure stable data transmission.

2. Multi-Signal Support – Supports analog and digital I/O, compatible with a variety of industrial devices.

3. Fast Response – Low-latency design ensures real-time control and data acquisition.

4. Modular Design – Easy integration with ABB controllers and I/O systems.

5. Industrial-Grade Reliability – Resistant to high temperatures and interference, suitable for harsh industrial environments.

6. Energy-Efficient Design – Low power consumption reduces system energy usage.

Applications

• Loop signal interface in PLC / DCS systems

• Industrial automation production line signal acquisition and control

• Industrial process data monitoring and transmission

• Signal conversion module in automation control cabinets

• Field device interface in energy management systems

• Multi-loop management and signal isolation applications

Precautions

1. Disconnect power before installation or maintenance to ensure safety.

2. Supply voltage must comply with module specifications to prevent damage.

3. Avoid operation in high humidity, dusty, or strong EMI environments.

4. Regularly check terminal connections and interface status to ensure reliable data transmission.

5. Use genuine ABB INLIM03 modules to ensure system compatibility and long-term reliable operation.
