ABB IMDSO15 digital output module
Item NO.:
IMDSO15Payment:
T/TPrice:
$1300Product Origin:
SwedenColor:
NEWProduct weight:
0.5KGLead Time:
in stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB IMDSO15 is a digital output module for the ABB AC500 PLC series. It converts control signals into switch outputs to drive relays, indicator lights, valves, or other digital actuators. The module provides reliable output performance and integrates seamlessly with ABB controllers and other I/O modules, suitable for various industrial automation applications.
The IMDSO15 module supports high switching frequency and short-circuit protection, ensuring long-term stable operation in industrial environments.
| Parameter | Specification / Description |
|---|---|
| Model | IMDSO15 |
| Module Type | Digital Output Module |
| Series | AC500 |
| Output Channels | 16 digital outputs |
| Output Type | Relay or transistor output (depending on version) |
| Output Voltage | 24 V DC (transistor) or max 230 V AC (relay) |
| Output Current | Max 0.5 A per channel (transistor) or 2 A (relay) |
| Switching Frequency | Max 50 Hz (relay), max 1 kHz (transistor) |
| Power Supply | 24 V DC ±10% |
| Isolation Voltage | 500 V AC (relay output) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Protection Class | IP20 (mounting inside control cabinet) |
| Dimensions | H 100 mm × W 50 mm × D 120 mm (DIN rail mount) |
| LED Indicators | Channel status, module power and fault indicators |
| Features | Digital output, short-circuit protection, status indication, multi-channel control |
High reliability output
Supports industrial load driving with overload and short-circuit protection for stable operation.
Multi-channel control
16 independent output channels for controlling multiple actuators.
Easy integration
Compatible with ABB AC500 controllers and I/O modules, allowing flexible system expansion.
Clear status indication
LED indicators on each channel for easy monitoring and troubleshooting.
DIN rail mounting
Modular design for quick installation and replacement in control cabinets.
Industrial environment adaptability
Wide operating temperature and humidity range, strong interference resistance.
Industrial automation control systems
Digital output control in PLC systems
Production line machinery control
Lights, valves, and relay control
Process control systems
HVAC and building automation systems
Power requirements
Use a stable 24 V DC power supply to ensure normal output operation.
Load matching
Ensure connected devices operate within module rated voltage and current.
Cooling and environment
Install in a ventilated control cabinet, maintain operating temperature 0°C to +60°C.
Short-circuit protection
Check wiring to avoid channel short or reverse connection for safe operation.
Status monitoring
Regularly check LED indicators to detect output anomalies or faults.
Protection measures
IP20 rating is suitable for cabinet installation to prevent dust or debris ingress.
