ABB IMDER01 Single-Drive Slave Module

Product Overview:
The ABB IMDER01 Single-Drive Slave Module is a dedicated slave module in ABB automation systems, designed for multi-axis or multi-drive systems to receive commands from the master controller and perform slave drive control. The module supports high-speed data communication and precise control, offering industrial-grade reliability and strong noise immunity, making it a key component in distributed drive control systems.

Technical Specifications:

• Model: IMDER01

• Type: Single-Drive Slave Module

• Drive Type: Motor drive slave module

• Control Modes: Speed, position, and torque control (per master controller commands)

• Communication Interfaces: EtherCAT / Profibus / Modbus (optional, system dependent)

• Operating Voltage: 24V DC (±10%)

• Power Consumption: ≤ 10 W

• Response Time: ≤ 2 ms

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +70°C

• Protection Class: IP20

• Mounting: DIN rail or rack-mounted

• Certifications: CE, UL, RoHS

Key Features and Advantages:

1. High-Speed Response – Supports fast slave control for multi-axis synchronization.

2. Multi-Protocol Compatibility – Compatible with multiple industrial communication protocols for flexible integration.

3. Modular Design – Easy installation and expandable for multi-drive systems.

4. Industrial Reliability – Strong noise immunity suitable for harsh environments.

5. Precise Control – Supports accurate speed, position, and torque control for improved motion performance.

6. Status Monitoring – Real-time module status monitoring enhances system safety and reliability.

Applications:

• Multi-axis servo drive systems

• Automated production lines and robotics

• Distributed drive control systems

• Motor control and energy management systems

• Industrial equipment in packaging, printing, textile, and machine tools

Precautions:

1. Always disconnect power before installation or removal.

2. Ensure proper grounding to prevent ESD and EMI damage.

3. Communication interfaces and protocols must match the master controller.

4. Do not plug or unplug the module under power.

5. Regularly check terminal connections and module mounting for secure contact.

6. Avoid high humidity, dust, or corrosive environments.
