ABB IISAC01 Digital Control Station

1. Key Parameters

• Product Model: IISAC01
• Order Code Reference: Typically paired with ABB system accessories (e.g., 3BSE008515R1 PROFIBUS DP cable, 3BSE003652R1 mounting kit, 3BSE004121R1 redundant power module)
• Product Series: ABB AC800M Local Control Stations (Digital HMI + Manual Control)
• Core Function: Provides local HMI for process monitoring (real-time data, alarms); enables manual parameter adjustment and control actions; synchronizes data with AC800M/800xA remote systems; supports emergency shutdown (ESD) and interlock functions
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Display Performance	- Size: 5.7-inch QVGA (320×240) - Technology: TFT LCD (anti-glare, high-brightness) - Brightness: 400 cd/m² - Contrast Ratio: 800:1	Visible at 5m (indoor); readable under direct industrial lighting
  Input Interface	- Tactile membrane keypad (16 keys: function keys + numeric keys) - 2× rotary encoders (for parameter adjustment, 100 steps/revolution) - 1× emergency stop (E-Stop) button (red, SIL 2 compliant)	Key lifespan: ≥1,000,000 presses; Encoder accuracy: ±1 step
  Communication Protocols	- Primary: PROFIBUS DP V1 (for data sync with AC800M) - Secondary: Modbus RTU (optional, for third-party device integration) - Baud rate: 9.6kbps~12Mbps (auto-negotiation)	Data sync latency: ≤100ms (with AC800M); Alarm transmission: ≤50ms
  Power Supply	24V DC ±10% (dual redundant inputs supported); Power consumption: ≤30W (full load, display + keypad)	Redundant power switchover: <5ms (prevents data loss during power failure)
  I/O Expansion	1× analog input (4~20mA, for local sensor); 1× analog output (4~20mA, for local actuator); 2× digital inputs (dry contact, for interlocks)	Supports direct connection of local sensors/actuators (no additional I/O module needed)

• Mechanical Specifications:
  • Housing Material: Aluminum alloy front panel (anti-corrosion coating) + flame-retardant ABS rear casing (UL94 V-0)
  • Dimensions (W×H×D): 180mm × 140mm × 80mm (panel-mounted design for tight process areas)
  • Mounting: Panel-mounted (cutout size: 165mm × 125mm); Optional wall-mount bracket (for non-panel installations)
  • Weight: Approximately 550g
  • Protection Rating: IP65 (front panel, dust-tight/waterproof against low-pressure jets); IP40 (rear casing)
  • LED Indicators:
    • Power (PWR1/PWR2): Green (redundant power active); Red (power fault)
    • Communication (COM): Green (sync with AC800M normal); Flashing green (data transmission); Red (comm fault)
    • Alarm (ALM): Red (active alarm); Amber (pending alarm)
• Environmental Ratings:
  • Operating Temperature Range: -20℃~+60℃ (-4℉~140℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 10%~95% RH (non-condensing, 40℃; suitable for damp process zones)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no display/keypad failure)
  • Shock Resistance: 20g acceleration (11ms duration, IEC 60068-2-27; maintains structural integrity)
  • EMC Immunity: Complies with IEC 61000-4-2 (ESD: ±8kV contact); IEC 61000-4-4 (EFT: ±2kV); IEC 61000-4-6 (RS: 10V/m) | Resists noise from motors/VFDs |
• Compliance Standards: IEC 61508 (SIL 2 for E-Stop), EN 61000-6-2 (EMC immunity), UL 508 (industrial safety), CE, RoHS, FDA 21 CFR Part 177 (food/pharmaceutical contact-compatible materials)

2. Key Features

• Local-Remote Synergy: Seamlessly synchronizes data with AC800M/800xA remote systems—operators can switch between "local control" (on-site manual operation) and "remote control" (DCS automatic control) without data loss, ensuring flexibility for both routine monitoring and emergency intervention.
• Rugged IP65 Front Panel: Dust-tight and waterproof design (IP65) withstands process-site conditions (e.g., chemical splashes, washdowns in food plants, dust in cement facilities)—ensures 99.9% uptime in harsh on-site environments.
• Intuitive Operation Interface: 5.7-inch anti-glare LCD, tactile membrane keypad, and rotary encoders simplify operation—no specialized training required for basic tasks (e.g., adjusting valve setpoints via encoder, acknowledging alarms via keypad), reducing operator error by 30%.
• SIL 2 E-Stop & Interlocks: Integrated red E-Stop button (SIL 2 compliant) and digital interlock inputs enable emergency shutdown of local processes—critical for high-risk zones (e.g., reactor overpressure, pump cavitation) where immediate action is needed.
• Redundant Power & Communication: Dual 24V DC power inputs (<5ms switchover) and PROFIBUS DP communication ensure continuous operation—prevents data loss or control failure during single power/communication faults, critical for 24/7 processes.
• Local I/O Expansion: Built-in analog/digital I/O ports support direct connection of local sensors (e.g., temperature probes) and actuators (e.g., small valves)—eliminates the need for additional distributed I/O modules, reducing installation cost and complexity.
• Food/Pharmaceutical Compatibility: Materials comply with FDA 21 CFR Part 177, and smooth front-panel design (no crevices) simplifies cleaning—suitable for food processing (e.g., filling lines) and pharmaceutical manufacturing (e.g., bioreactor zones) with strict hygiene requirements.

3. Application Fields

• Process Industry Local Control: Primary application—on-site monitoring/control of high-risk process zones:
  • Chemical Reactor Zones: Enables operators to monitor reactor temperature/pressure (via LCD) and adjust dosing pump speed (via rotary encoder) directly at the reactor; E-Stop triggers immediate shutdown if pressure exceeds safety limits, preventing explosions.
  • Oil Refinery Distillation Units: Displays column tray temperatures and flow rates; manual control of reflux valve position (via keypad) during DCS maintenance, ensuring continuous distillation without process shutdown.
• Power Plant Auxiliary Systems: On-site operation of critical power equipment:
  • Thermal Power Plant Boiler Rooms: Monitors boiler feedwater pressure and steam temperature; adjusts feedwater valve setpoints locally (via encoder) to maintain boiler efficiency, while E-Stop shuts down feedwater pumps during low-water conditions.
  • Hydropower Station Turbine Halls: Displays turbine speed and lubricating oil pressure; manual start/stop of auxiliary pumps (via keypad) during remote system upgrades, avoiding turbine downtime.
• Water & Wastewater Treatment: Local control of treatment processes:
  • Wastewater Aeration Zones: Monitors dissolved oxygen (DO) levels and blower speed; adjusts blower frequency (via analog output) to maintain optimal DO, while interlock inputs from level sensors prevent aeration during tank overflow.
  • Drinking Water Filtration Plants: Displays filter turbidity and backwash status; manual initiation of backwash cycles (via keypad) when remote DCS signals are delayed, ensuring water quality compliance.
• Food & Pharmaceutical Manufacturing: Hygienic local control:
  • Food Filling Lines: Monitors filling temperature and volume; adjusts filling speed (via encoder) to prevent overfilling, while IP65 front panel withstands daily washdowns with food-safe sanitizers.
  • Pharmaceutical Bioreactors: Displays bioreactor pH and agitation speed; manual adjustment of pH dosing (via keypad) during batch cultivation, with FDA-compliant materials avoiding product contamination.

The structure and details of the product：
