ABB IIMCP01 multi-bus communication processor card

1. Product Overview

The ABB IIMCP01 Multi-Bus Communication Processor Card is a core communication module for ABB INFI 90 Distributed Control Systems (DCS), managing multiple bus interfaces to enable high-speed data exchange between distributed I/O modules and the main controller.
It collects, processes, and transmits data from DI/DO/AI/AO I/O modules through the system bus, ensuring reliable and real-time communication.
The IIMCP01 provides high-speed processing, error detection, and diagnostic capabilities, enhancing system responsiveness, reliability, and flexibility in industrial automation applications.

2. Technical Specifications

3. Features & Advantages

• Multi-bus support allows simultaneous management of multiple serial bus interfaces.

• High-speed data processing ensures real-time communication with distributed I/O modules.

• Wide module compatibility supports DI, DO, AI, AO modules.

• Electrical isolation prevents bus interference and enhances system stability.

• Modular design for plug-in installation, expansion, and maintenance.

• Industrial-grade reliability suitable for continuous operation in complex environments.

4. Application Areas

• Core communication processor for ABB INFI 90 / Bailey / Symphony DCS

• Industrial automation and process control systems

• Petrochemical, power plant, and metallurgical process monitoring

• Water treatment and environmental monitoring

• Automated production lines and energy management systems

• Multi-bus communication management in distributed control systems

5. Precautions

1. Disconnect system power before installation or maintenance.

2. Ensure proper insertion to avoid bus interface damage.

3. Use shielded cables and proper grounding to prevent interference.

4. Periodically check module operation and communication LEDs.

5. Avoid prolonged exposure to high humidity, high temperature, or corrosive environments.

6. Do not disassemble or modify internal circuits.

7. Use only ABB-certified modules and accessories.
