ABB IEPEP03 Power Input Panel

1. Key Parameters

• Product Model: IEPEP03
• Order Code Reference: Typically paired with ABB system accessories (e.g., 3BSE008519R1 AC power cables, 3BSE003659R1 circuit breakers, 3BSE004125R1 surge arresters, 3BSE004126R1 mounting hardware)
• Product Series: ABB AC800M Power Distribution Panels (Industrial AC Power Reception & Protection)
• Core Function: Receives 3-phase/1-phase AC power from plant grids; provides surge, overload, and short-circuit protection; filters grid noise to stabilize power quality; distributes conditioned power to AC800M controllers and power units; monitors power status (voltage/current) and triggers fault alerts
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Input Power Capacity	- Voltage Range: 1-phase: 110V/230V AC ±10% (50/60Hz) 3-phase: 380V/400V/480V AC ±10% (50/60Hz) - Input Current: 63A max (continuous); 100A peak (10s) - Input Connection: 3-phase 4-wire (L1/L2/L3/N) + PE	Compatible with global industrial AC grids (low/high voltage)
  Output Power Distribution	- Output Circuits: 6 independent protected circuits (3× 16A, 3× 32A) - Output Voltage: Same as input (regulated via noise filter) - Isolation: Circuit-to-circuit isolation (2kVrms, 1min dielectric test)	Powers multiple downstream components (e.g., 2× AC800M controllers + 4× IEPMU01 units)
  Protection Features	- Surge Protection: IEC 61000-4-5 (±10kV common mode, ±5kV differential mode) via integrated surge arresters - Overload/Short-Circuit Protection: Thermal-magnetic circuit breakers (16A/32A) per output circuit (trip time: ≤0.1s at 10× rated current) - Overvoltage Protection: 110% of rated voltage (clamping via varistors) - Reverse Polarity Protection: No damage from reversed phase wiring	Prevents grid transients (lightning, voltage spikes) from damaging AC800M systems
  Power Quality & Monitoring	- Noise Filter: 50Hz/60Hz notch filter (attenuation: ≥40dB @ 1kHz~100kHz) - Monitoring: Digital display for input voltage (±0.5% accuracy) and current (±1% accuracy); LED status for each output circuit - Fault Alerts: Dry contact outputs (2×, 1A AC 250V) for input fault/output overload	Reduces grid noise interference; enables remote power status tracking via AC800M DCS

• Mechanical Specifications:
  • Housing Material: Cold-rolled steel (powder-coated, anti-corrosion); Front door: Tempered glass (lockable)
  • Dimensions (W×H×D): 600mm × 800mm × 250mm (floor-standing or wall-mounted; fits standard control room switchgear bays)
  • Mounting: Floor-standing (with adjustable feet) or wall-mounted (via rear mounting brackets); IP rating: IP30 (front panel, dust-protected)
  • Weight: Approximately 35kg
  • Terminals & Connectors:
    - Input: 63A bolt-type terminals (L1/L2/L3/N/PE)
    - Output: 16A/32A screw terminals (per circuit)
    - Monitoring: RS485 port (Modbus RTU) for remote data transmission
  • LED Indicators:
    - Input Power (L1/L2/L3): Green (phase active); Red (phase loss)
    - Output Circuits (OUT1~OUT6): Green (circuit active); Red (breaker tripped)
    - System (SYS): Green (normal); Amber (warning: 80% load); Red (critical fault)
• Environmental Ratings:
  • Operating Temperature Range: -10℃~+50℃ (14℉~122℉)
  • Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
  • Humidity Tolerance: 10%~90% RH (non-condensing, 40℃; suitable for control room environments)
  • Vibration Resistance: 5~500Hz, 0.5g acceleration (IEC 60068-2-6; no circuit breaker tripping)
  • EMC Immunity: Complies with IEC 61000-4-2 (ESD: ±15kV air discharge); IEC 61000-4-4 (EFT: ±4kV) | Resists noise from high-voltage plant grids |
• Compliance Standards: IEC 60439-1 (low-voltage switchgear), EN 61000-6-2 (EMC immunity), UL 508A (industrial control panels), CE, RoHS, IEC 61508 (SIL 1 capable for power distribution loops)

2. Key Features

• Dual-Input Voltage Compatibility: Supports both 1-phase (110V/230V) and 3-phase (380V/400V/480V) AC input—eliminates the need for separate panels for different plant grid voltages, enabling global deployment in diverse industrial sites (e.g., 230V single-phase in Europe, 480V 3-phase in North America).
• Industrial-Grade Surge & Overload Protection: Integrated surge arresters (±10kV) and thermal-magnetic circuit breakers protect AC800M systems from grid transients (lightning, motor startup spikes) and overloads—prevents costly damage to controllers and I/O modules, reducing unplanned downtime by 70%.
• Grid Noise Filtration: 50Hz/60Hz notch filter attenuates high-frequency noise (1kHz~100kHz) from plant equipment (e.g., VFDs, motors)—ensures stable power for AC800M’s sensitive electronics (e.g., CPU, communication chips), avoiding data corruption or controller reset.
• Multi-Circuit Distributed Power: 6 independent protected output circuits (3×16A, 3×32A) enable targeted power distribution—supplies dedicated circuits to AC800M controllers (16A), IEPMU01 power units (32A), and auxiliary devices (e.g., HMI panels), isolating faults to single circuits (e.g., a tripped 16A breaker won’t affect IEPMU01 power).
• Real-Time Power Monitoring: Digital voltage/current display and Modbus RTU communication provide visibility into power status—operators can track input voltage fluctuations (e.g., 400V → 380V) and output load levels (e.g., 25A on a 32A circuit) via AC800M DCS, enabling proactive maintenance.
• Safety-Compliant Design: Lockable tempered glass door, IP30 dust protection, and circuit isolation (2kVrms) meet global electrical safety standards (UL 508A, IEC 60439-1)—prevents unauthorized access and reduces shock risks for maintenance personnel.
• SIL 1 Power Distribution: Meets IEC 61508 SIL 1 requirements for power loops—suitable for low-risk safety-related power distribution (e.g., powering non-critical I/O racks), ensuring basic fault mitigation aligned with industrial safety protocols.

3. Application Fields

• AC800M System Power Hub: Primary application—front-end power for AC800M automation systems:
  • Chemical Plant Control Rooms: Receives 3-phase 400V AC from the plant grid, filters noise, and distributes power to 2× AC800M PM864 controllers (16A circuits), 3× IEPMU01 power units (32A circuits), and 1× IIADP01 annunciator panel (16A circuit); surge protection guards against voltage spikes from chemical process pumps.
  • Automotive Factory Switchgear: Takes 3-phase 480V AC input, isolates circuits for 4× AC800M-based assembly line controllers (16A each) and 2× IEPMU01 units (32A each); noise filtration eliminates interference from welding robots, ensuring stable controller operation.
• Power Generation Plant Power Distribution: Reliable power for critical control systems:
  • Thermal Power Plant Auxiliary Control: Receives 3-phase 380V AC from the plant’s auxiliary grid, distributes power to AC800M turbine control units (16A), IEPMU01-powered I/O racks (32A), and safety system panels (16A); monitoring tracks voltage dips during generator startup, preventing controller reset.
  • Hydropower Station Control Panels: Uses 1-phase 230V AC input to power small AC800M systems (e.g., dam gate control), 2× IEPMU01 units (32A), and CCTV cameras (16A); lockable door prevents unauthorized access to critical power circuits.
• Oil & Gas Facility Power Reception: Rugged power for hazardous-area support systems:
  • Oil Refinery Central Control: Receives 3-phase 400V AC, filters noise from refinery compressors, and distributes power to AC800M distillation control systems (16A), IEPMU01 units for field I/O (32A), and fire alarm panels (16A); surge protection withstands lightning-induced transients in open refinery areas.
  • Offshore Platform Control Huts: Wall-mounted design saves space, receiving 3-phase 400V AC (via platform grid) and powering 1× AC800M controller (16A), 2× IEPMU01 units (32A), and communication modules (16A); corrosion-resistant steel housing withstands saltwater humidity.
• Infrastructure & Utility Power Distribution: Public service automation support:
  • Municipal Water Treatment Plants: Receives 3-phase 380V AC, distributes power to AC800M treatment process controllers (16A), IEPMU01 units for pump I/O (32A), and SCADA servers (16A); monitoring alerts operators to voltage drops that could affect pump performance.
  • Data Center Automation: Uses 3-phase 480V AC input to power AC800M-based HVAC control systems (16A), IEPMU01 units for server rack sensors (32A), and backup generator transfer switches (32A); noise filtration ensures stable power for sensitive HVAC electronics.

The structure and details of the product：
