ABB HIEE401481R0001 High-Performance Analog and Digital I/O Card

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB HIEE401481R0001 High-Performance Analog and Digital I/O Card – Product Information

1. Product Overview

The ABB HIEE401481R0001 is a high-performance analog and digital I/O card designed for ABB industrial automation and control systems.
It provides high-speed, high-precision analog and digital signal acquisition and output, suitable for industrial control, process monitoring, and automation data acquisition applications.
Modular design ensures flexible system expansion and compatibility with ABB drives and PLC control modules.

2. Technical Specifications

• Model: HIEE401481R0001

• Type: High-Performance Analog & Digital I/O Card

• Compatible Systems: ABB PLCs, control modules, and drives

• Analog Inputs: ±10 V / 0-20 mA (configurable, 16-bit resolution)

• Analog Outputs: ±10 V / 0-20 mA (16-bit resolution)

• Digital Inputs: 24 V DC (optically isolated)

• Digital Outputs: 24 V DC / 0.5 A (can drive relays or logic inputs)

• Sampling Rate: Up to 10 kHz

• Response Time: < 1 ms

• Supply Voltage: 24 V DC

• Operating Temperature: -25 ℃ to +70 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Humidity: 5% to 95%, non-condensing

• Protection Class: IP20

• Mounting: Slot-in or DIN rail mount

• Dimensions: Approx. 180 × 100 × 35 mm

• Weight: Approx. 0.45 kg

• Certifications: CE, UL, RoHS, IEC 61131

3. Features and Advantages

1. High-speed signal processing – Supports up to 10 kHz analog/digital sampling.

2. High accuracy – 16-bit ADC/DAC resolution ensures precise data acquisition.

3. Multi-function interfaces – Supports both analog and digital I/O.

4. Modular design – Easily expandable I/O points for system upgrades.

5. Strong interference immunity – Optically isolated with EMI/EMC optimization.

6. Compact and reliable – Saves control cabinet space and allows easy installation and maintenance.

4. Application Areas

• Industrial automation and control systems

• PLC module expansion and data acquisition

• Motor control and drive systems

• Factory automation production line monitoring

• Energy management and distribution monitoring

• Smart building and process control systems

5. Precautions

1. Installation and wiring must be performed by qualified personnel.

2. Disconnect power before wiring to prevent electric shock or module damage.

3. Do not exceed rated voltage, current, or temperature limits.

4. Periodically check terminal connections and interfaces for reliability.

5. Use protective measures in high humidity, dusty, or corrosive environments.

6. Follow ABB recommended procedures for maintenance and replacement.

The structure and details of the product：
