ABB HIEE320639R1 pulse amplifier

ABB HIEE320639R1 Pulse Amplifier – Product Information

1. Product Overview

The ABB HIEE320639R1 is a high-performance pulse amplifier designed for power automation systems.
It receives weak pulse signals and amplifies them into standard signals that can be processed by the control system, enabling precise monitoring and control. The HIEE320639R1 is suitable for power plants, substations, and industrial automation systems, ensuring stable and reliable signal transmission.

2. Technical Specifications

• Model: HIEE320639R1

• Type: Pulse Amplifier

• Input Signal Type: Pulse signal (TTL or square wave)

• Input Voltage Range: 0 ~ 24 V DC

• Output Signal Type: Amplified pulse signal

• Output Voltage: 24 V DC

• Response Time: < 1 μs

• Operating Temperature: -20 ℃ to +60 ℃

• Storage Temperature: -30 ℃ to +85 ℃

• Supply Voltage: 24 V DC

• Power Consumption: Approx. 6 W

• Communication Interface: Standard analog/digital interface

• Dimensions: Approx. 120 × 100 × 40 mm

• Weight: Approx. 1.2 kg

• Protection Class: IP20

• Certifications: CE, RoHS

3. Features and Advantages

1. High-Precision Signal Amplification – Amplifies weak pulse signals into standard signals for improved system accuracy.

2. High-Speed Response – Response time less than 1 microsecond, suitable for real-time control.

3. Industrial-Grade Reliability – Anti-interference design suitable for harsh industrial environments.

4. Multi-Signal Compatibility – Supports TTL and square wave pulse signal inputs.

5. Modular Design – DIN rail mounting for easy integration and maintenance.

6. Remote Monitoring and Control – Supports signal monitoring and diagnostics via control systems.

4. Application Areas

• Power plant excitation control systems

• Industrial automation control systems

• Substation automation and monitoring

• Pulse counting and measurement systems

• Industrial process data acquisition and signal processing systems

5. Precautions

1. Confirm the input signal type is compatible with the module before installation.

2. Maintain a stable supply voltage to avoid affecting module performance.

3. Avoid use in high humidity, corrosive, or high electromagnetic interference environments.

4. Regularly inspect module operation and interface connections to ensure normal system operation.

5. Installation and maintenance must be performed by trained professionals; do not disassemble or modify the module.
